BPU-230HD-BPL 2x 5.25" to 3x 3.5" 2.5" 12Gb/s HDD SSD Hot-swap Rack
Quantity:
- SKU: 12841826
- Manufacturer: ISTARUSA
- MPN: BPU-230HD-BPL
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$102.35
BPU-230HD-BPL 2x 5.25" to 3x 3.5" 2.5" 12Gb/s HDD SSD Hot-swap Rack
Create more space for hard drive with hot-swap capability, BPU-230HD-BPL supports RAID 1/0/1+0/5 configuration for high performance or redundancy data application. Aluminum construction provides light weight but strong stability and extra 70mm fan keep hard drive at maximum performance. High density multi-disk storage backplane that allows multiple 3x3.5" SAS/SATA hard drives to be mounted into 2 standard 5.25". Aluminum construction provides best heat dissipation required for high performance SAS/SATA drives, is designed with excellent front to back vent airflow. Applications: Digital Audio Editing,Video Editing (SD or HD),Security System,SOHO SMEs With Limit HDD Tray and Data Protection or Disk-to-Disk Backup
Create more space for hard drive with hot-swap capability, BPU-230HD-BPL supports RAID 1/0/1+0/5 configuration for high performance or redundancy data application. Aluminum construction provides light weight but strong stability and extra 70mm fan keep hard drive at maximum performance. High density multi-disk storage backplane that allows multiple 3x3.5" SAS/SATA hard drives to be mounted into 2 standard 5.25". Aluminum construction provides best heat dissipation required for high performance SAS/SATA drives, is designed with excellent front to back vent airflow. Applications: Digital Audio Editing,Video Editing (SD or HD),Security System,SOHO SMEs With Limit HDD Tray and Data Protection or Disk-to-Disk Backup
BPU-230HD-BPL 2x 5.25" to 3x 3.5" 2.5" 12Gb/s HDD SSD Hot-swap Rack
- Stylish aluminum color handle and heat-sink body
- Support Hot-Swap & RAID Configuration (need an additional RAID controller)
- Aluminum Design with Conductive Dissipation Grooves
- Power, fan and high temperature LED indicators
- High Performance Transfer Rate up to 12Gb/s
- Supports Both 2.5" and 3.5" SAS I/II/III & SATA I/II/III HDD/SSD
- Equipped with Fan Speed Control Switch
- 14TB Hard Drives Compatible
| Model Number | BPU-230HD-BPL |
| RoHS Compliance | Yes |
| Standard Drive Bays | Hotswap 3.5": 3
5.25" Drives: 2 |
| Hotswap HDD Type: | 2.5" & 3.5" SAS I/II/III & SATA I/II/III |
| Indicators | Power, HDD, fan, and high temperature |
| Material of Front Bezel | Aluminum |
| Material of Handle | Aluminum |
| Material of Main Chassis | Aluminum Design with Conductive Dissipation Grooves |
| Color of Front Bezel | Black |
| Color of Main Chassis | Black |
| Package Content | SATA Cable Included (3pcs) |
| Cooling Fan | 1x70mm |
| Ordering Information
(Part Number) |
Lockable Tray:BPU-230HD-BPL |
| Dimensions (WxHxD) | 5.75" x 3.39" x 8.22"
146.0 mm x 86.1 mm x 208.8 mm |
