BPU-340HD-BLACK 3x 5.25" to 4x 3.5" 2.5" 12Gb/s HDD SSD Hot-swap Rack

SKU: 12841831

Manufacturer: ISTARUSA

MPN: BPU-340HD-BLACK

Availability: Unknown


Price: $116.15
or as low as $4/month
Quantity:

High level Raid and high availability storage in compact design, BPU-340HD-BLACK adds extra storage and hot-swap capability to satisfy any application needs. Aluminum body and extra 80mm cooling fan subsystem complete a high end data storage server or workstation. High density multi-disk storage backplane that allows multiple four 3.5" SAS/SATA hard drives to be mounted into three standard 5.25" drive bays. BPU-340HD supports RAID 1/0/1+0/5 configuration for high performance or redundancy data application. Aluminum construction provides best heat dissipation required for high performance SAS/SATA drives, is designed with excellent front to back vent airflow. Applications: Digital Audio Editing,Video Editing (SD or HD), Security System, SOHO SMEs With Limit HDD Tray and Data Protection or Disk-to-Disk Backup.

BPU-340HD-BLACK 3x 5.25" to 4x 3.5" 2.5" 12Gb/s HDD SSD Hot-swap Rack

  • Stylish aluminum color handle and heat-sink body
  • Support Hot-Swap & RAID Configuration (need an additional RAID controller)
  • Aluminum Design with Conductive Dissipation Grooves
  • Power, fan and high temperature LED indicators
  • High Performance Transfer Rate up to 12Gb/s
  • Supports Both 2.5" and 3.5" SAS I/II/III & SATA I/II/III HDD/SSD
  • Equipped with Fan Speed Control Switch
  • 14TB Hard Drives Compatible
Model Number BPU-340HD-BLACK
RoHS Compliance Yes
Standard Drive Bays Hotswap 3.5": 4
5.25" Drives: 3
Hotswap HDD Type: 2.5" & 3.5" SAS I/II/III & SATA I/II/III
Indicators Power, HDD, fan, and high temperature
Material of Front Bezel Aluminum
Material of Handle Aluminum
Material of Main Chassis Aluminum Design with Conductive Dissipation Grooves
Color of Front Bezel Black
Color of Main Chassis Black
Package Content SATA Cable Included (4pcs)
Cooling Fan 1x80mm
Ordering Information
(Part Number)
Black Tray:BPU-340HD-BLACK
Dimensions (WxHxD) 5.75" x 4.96" x 8.03"
146.0 mm x 126.0 mm x 204.0 mm
