High level Raid and high availability storage in compact design, BPU-340MS series adds extra storage and hot-swap capability to satisfy any application needs. Aluminum body and extra 80mm cooling fan subsystem complete a high end data storage server or workstation. High density multi-disk storage backplane that allows multiple four 3.5" SAS/SATA hard drives to be mounted into three standard 5.25" drive bays. BPU-340MS supports RAID 1/0/1+0/5 configuration for high performance or redundancy data application. Aluminum construction provides best heat dissipation required for high performance SAS/SATA drives, is designed with excellent front to back vent airflow. Applications: Digital Audio Editing,Video Editing (SD or HD), Security System, SOHO SMEs With Limit HDD Tray and Data Protection or Disk-to-Disk Backup.
Model Number | BPU-340MS-BLACK |
RoHS Compliance | Yes |
Standard Drive Bays | Hotswap 3.5": 4
5.25" Drives: 3 |
Hotswap HDD Type: | 2.5" & 3.5" SAS I/II/III & SATA I/II/III |
Indicators | Power, HDD, fan, and high temperature |
Material of Front Bezel | Aluminum |
Material of Handle | Aluminum |
Material of Main Chassis | Aluminum Design with Conductive Dissipation Grooves |
Color of Front Bezel | Black/ Blue/ Red/ Silver |
Color of Main Chassis | Black |
Package Content | SATA Cable Included (4pcs) |
Cooling Fan | 1x80mm |
Ordering Information
(Part Number) |
Black Tray:BPU-340MS-BLACK
Blue Tray:BPU-340MS-BLUE Red Tray:BPU-340MS-RED Silver Tray:BPU-340MS-SILVER Lockable Tray:BPU-340MS-BPL |
Dimensions (WxHxD) | 5.75" x 4.96" x 8.03"
146.0 mm x 126.0 mm x 204.0 mm |
