CP1500PFCLCDTAA, LCD, 1500 VA/1000 W, Sine Wave, Tower UPS - TAA Compliant
- SKU: 7146863
- Manufacturer: CYBERPOWER SYSTEMS
- MPN: CP1500PFCLCDTAA
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
CyberPower's Federal Trade Agreements Act (TAA) compliant CP1500PFCLCD PFC Series UPS with Pure Sine Wave output safeguards mid to high-end computer systems that use conventional and Active Power Factor Correction (PFC) power supplies.
Its automatic voltage regulation (AVR) topology delivers clean and consistent AC power. Its patented GreenPower UPS advanced circuitry reduces UPS energy costs by up to 75% compared to competitive models.
The CP1500PFCLCDTAA has a capacity of 1500VA/900Watts, (10) NEMA 5-15R receptacles and (2) maintenance-free, user-replaceable 12V/8.5Ah batteries. The intelligent multi-function LCD panel displays real-time UPS vitals for ease of
control. Connectivity via (1) HID USB and (1) DB9 serial ports. Surge Protection for RJ11/RJ45 & coax. Two 5Vdc USB 2.0 charging ports for portable devices.
PowerPanel Personal Edition UPS Management software, a standard Three-Year Warranty and a $500,000 Connected Equipment Guarantee are included.
- Capacity:1500VA / 1000W
- Topology:Line Interactive
- Waveform:Sine Wave
- Output:120Vac ± 5%
- Plug type & cord:NEMA 5-15P, 5 ft. cord
- Outlet types:12 × NEMA 5-15R
- USB charge ports:2
- Communication:USB, Relay, SNMP
- Data line protection:Network
- Management software:PowerPanel® Business
- Remote management:Yes, with optional RMCARD205TAA
- ENERGY STAR® certified:Yes
- Warranty:3 year
| General | |
| Active PFC Compatible | Yes |
| Energy Saving | GreenPower UPS™ Bypass Technology |
| Energy Star Certified | Yes |
| UPS Topology | Line Interactive |
| Battery | |
| Battery Quantity | 2 |
| Battery Size | 12 V / 9 Ah |
| Battery Type | Sealed Lead-Acid Battery |
| Hot Swappable | Yes |
| Replacement Battery Cartridge |
RB1290X2 RB1280X2B (for serial numbers beginning witd CQ9, CTF) |
| Replacement Battery Cartridge Quantity | 1 |
| Runtime at Full Load | 2.5 min |
| Runtime at Half Load | 10 min |
| Typical Recharge Time | 8 Hours |
| User Replaceable Battery | Yes |
| Input | |
| Circuit Breaker | 15 A |
| Cord Lengtd | 5 ft (1.5 m) |
| Input Frequency Range | 57 Hz – 63 Hz |
| Input Plug Type | NEMA 5-15P |
| Input Voltage Range | 88 VAC – 144 VAC |
| Nominal Input Voltage | 120 VAC |
| Plug Style | Right Angle – 45° Offset |
| Output | |
| Automatic Voltage Regulation | Single Boost |
| On AC WaveForm | Sine Wave |
| On Battery Frequency | 60 Hz ± 1% |
| On Battery Voltage | 120 VAC ± 5% |
| On Battery Waveform | Sine Wave |
| Outlet Type | 12 – NEMA 5-15R |
| Outlets – Battery & Surge Protected | 6 |
| Outlets – Surge-Only Protected | 6 |
| Outlets – Total | 12 |
| Outlets – Widely Spaced | 2 |
| Output Power Factor | 0.7 |
| Overload Protection |
Internal Circuitry Limiting Circuit Breaker Protected |
| Typical Transfer Time | 4 ms |
| USB Charge Port | Yes |
| USB Charge Port Amperage | 3.1 Amps (Shared) |
| USB Charge Port Quantity | 2 |
| USB Charge Port Type |
1 Type A 1 Type C |
| USB Charge Port Voltage | 5 VDC |
| Under/Over-Voltage Correction | +11.5% |
| VA | 1500 VA |
| Watts | 1000 W |
| Surge Protection & Filtering | |
| EMI/RFI Filtration | Yes |
| Network Protection RJ45 | 1-in / 1-Out (10/100/1000) + PoE Compatible |
| Surge Suppression (Joules) | 1445 J |
| Management & Communications | |
| Audible Alarms |
Battery Mode Low Battery Overload Fault |
| Emergency Power Off (EPO) Port | No |
| HID Compliant USB Port | Yes |
| LCD | Multifunction LCD |
| LED Indicators |
Power On Wiring Fault |
| Management Cable | USB Cable |
| SNMP / HTTP Remote Monitoring | Yes – witd optional RMCARD205TAA |
| Serial Port | 1 Dry Contact |
| Software (Free Download) | PowerPanel® Business |
| Physical | |
| Color | Black |
| Form Factor | Mini-Tower |
| Material of Construction | Plastic |
| Dimensions | |
| Physical Dimensions – (WxHxD) (cm) | 9.91 x 27.94 x 35.56 (cm) |
| Physical Dimensions – (WxHxD) (in) | 3.9 x 11.0 x 14.0 (in) |
| Physical Dimensions – (WxHxD) (mm) | 99 x 279 x 356 (mm) |
| Physical Weight (kg) | 11.29 |
| Physical Weight (lb) | 24.9 |
| Dimensions – Shipping | |
| Shipping – Weight (kg) | 12.88 |
| Shipping – Weight (lb) | 28.4 |
| Shipping Dimensions – (WxHxD) (cm) | 19.69 x 36.83 x 44.45 (cm) |
| Shipping Dimensions – (WxHxD) (in) | 7.75 x 14.5 x 17.5 (in) |
| Shipping Dimensions – (WxHxD) (mm) | 196.85 x 368.3 x 444.5 (mm) |
| Environmental | |
| Operating Elevation | 0 – 10000 ft (0 – 3048 m) |
| Operating Relative Humidity | 0 – 95 % (non-condensing) |
| Operating Temperature | 32 – 104 °F (0 – 40 °C) |
| Storage Temperature | 5 – 113 °F (-15 – 45 °C) |
| Certifications | |
| Environmental | RoHS Compliant |
| Safety |
UL1778 cUL 107.3 FCC DOC Class B |
| Warranty | |
| Connected Equipment Guarantee | Lifetime |
| Extended Warranty Option | WEXT5YR-U2A |
| Product Warranty | 3 Year Limited Warranty |
