Input | |
---|---|
Voltage | 125 V |
Plug Type | NEMA 5-15P |
Plug Style | Right Angle, 45° Offset Right |
Switch | Non Lighted On/Off - Reset |
Circuit Breaker | 15 A |
Cord Length | 6 ft |
Output | |
Outlet Type | NEMA 5-15R |
Outlets - Total | 8 |
Outlets - Widely Spaced | 4 |
Surge Protection & Filtering | |
Surge Suppression | 2,250 joules |
Maximum Surge Current | 120,000 amps |
Maximum Surge Current H-N | 60,000 amps |
Maximum Surge Current H-G | 30,000 amps |
Maximum Surge Current N-G | 30,000 amps |
Clamping Voltage | 400 V (L-N, L-G, N-G) |
Response Time | < 1 nanosecond |
Phone Protection RJ11 | 1-In, 2-Out |
EMI/RFI Filtration | 150 kHz – 100 MHz |
Attenuation | Up to 43 dB |
Network Protection RJ45 | None |
Indicators | |
Indicators | Protected (green) Grounded (green) |
Certifications | |
Safety | UL1363 UL1449 3rd Edition cUL |
Environmental | RoHS Compliant |
Warranty | |
Product Warranty | Limited Lifetime |
Connected Equipment Guarantee | Lifetime |
CEG Amount | $250,000 |
Physical | |
Keyhole Mounting Slots | Yes |
Cord Management | Yes |
Safety Covers | Yes |
