Core P6 TG Snow Tempered Glass, No PSU, ATX, White, Mid Tower Case

Core P6 Tempered Glass Snow ATX Mid Tower Chassis

The Core P6 TG Snow Mid Tower Case is the smaller version of the Core P8 TG Full Tower Case. Just like the Core P8 TG, the Core P6 TG Snow can be transformed into a closed or open styled form effortlessly and is the newest member of the Thermaltake iconic open-frame Core Series. The Core P6 TG Snow features a fully modular design, Rotational PCI-E Slots, a PSU cover, an extra GPU bracket, support for 120mm and 140mm fans, support for 360mm and 280mm radiators, and removable filters. With all the significant features, the potential for the hardware expansion and cooling solution is remarkable for the Core P6 TG Snow. Users will enjoy the process of building in the Core P6 TG Snow Mid Tower Case and find it truly unique and innovative.

P/N CA-1V2-00M6WN-00
Series Core
Model Core P6 TG Snow
Case Type Mid Tower
Dimension (H x W x D) 565 x 255 x 530mm
(22.2 x 10 x 20.9 inch)
Net Weight 17.84 kg / 39.33 lbs.
Side Panel 4mm Tempered Glass x 3
Color Black
Material SPCC
Cooling System -
Drive Bays
-Accessible
-Hidden
4 x 3.5” or 8 x 2.5”
Expansion Slots 7 (Rotatable Patented Design)
Motderboards 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 10.5”(CEB)
I/O Port USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1
PSU Standard PS2 PSU (optional)
Fan Support Front:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Top:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Rear:
1 x 120mm
Right (M/B Side):
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Bottom:
3 x 120mm, 2 x 120mm or 1 x 120mm
2 x 140mm, 1 x 140mm
Radiator Support Front:
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Top:
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Rear:
1 x 120mm
Right (M/B Side):
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Bottom:
1 x 240mm, 1 x 120mm
Clearance CPU cooler height limitation:
180mm
VGA lengtd limitation:
300mm (Witd Reservoir)
400mm (Witdout Reservoir)
430mm (Witd Radiator)
458mm (Witdout Radiator)
PSU lengtd limitation:
200mm
