Core™ Ultra 5 245KF 14 (6P+8E) Cores 3.6 - 5.2GHz Turbo, LGA 1851, 159W MTP, Processor

Quantity:
  • SKU: 18061444
  • Manufacturer: INTEL
  • MPN: BX80768245KF
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$319.42
Quantity:
Essentials
Product Collection Intel® Core™ Ultra Processors (Series 2)
Code Name Products formerly Arrow Lake
Vertical Segment Desktop
Processor Number  245KF
Overall Peak TOPS (Int8)  22
CPU Specifications
Total Cores  14
# of Performance-cores 6
# of Efficient-cores 8
Total Threads  14
Max Turbo Frequency  5.2 GHz
Performance-core Max Turbo Frequency  5.2 GHz
Efficient-core Max Turbo Frequency  4.6 GHz
Performance-core Base Frequency  4.2 GHz
Efficient-core Base Frequency  3.6 GHz
Cache  24 MB Intel® Smart Cache
Total L2 Cache 26 MB
Processor Base Power  125 W
Maximum Turbo Power  159 W
Intel® Deep Learning Boost (Intel® DL Boost) on CPU  Yes
AI Software Frameworks Supported by CPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography  TSMC N3B
Supplemental Information
Marketing Status Launched
Launch Date  Q4'24
Embedded Options Available  No
Use Conditions  PC/Client/Tablet
Memory Specifications
Max Memory Size (dependent on memory type)  192 GB
Memory Types  Up to DDR5 6400 MT/s
Maximum Memory Speed 6400 MHz
Max # of Memory Channels  2
NPU Specifications
NPU Name Intel® AI Boost
NPU Peak TOPS (Int8)  13
Sparsity Support Yes
Windows Studio Effects Support Yes
AI Software Frameworks Supported by NPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
Expansion Options
Direct Media Interface (DMI) Revision 4
Max # of DMI Lanes 8
Intel® Thunderbolt™ 4  Yes
Scalability 1S Only
PCI Express Revision  5.0 and 4.0
PCI Express Configurations   Up to 1x16+2x4, 2x8+2x4,
1x8+4x4
Max # of PCI Express Lanes  24
Package Specifications
Sockets Supported  FCLGA1851
Thermal Solution Specification  PCG 2020A
Max Operating Temperature  105 °C
Advanced Technologies
Intel® Volume Management Device (VMD)  Yes
Intel® Gaussian & Neural Accelerator  3.5
Intel® Thread Director  Yes
Intel® Speed Shift Technology  Yes
Intel® Turbo Boost Technology   2.0
Intel® 64   Yes
Instruction Set  64-bit
Instruction Set Extensions  Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States  Yes
Enhanced Intel SpeedStep® Technology  Yes
Thermal Monitoring Technologies  Yes
Security & Reliability
Intel® Standard Manageability (ISM)   Yes
Intel® Control-Flow Enforcement Technology  Yes
Intel® AES New Instructions  Yes
Secure Key  Yes
Intel® Trusted Execution Technology   Yes
Execute Disable Bit   Yes
Intel® OS Guard Yes
Intel® Boot Guard  Yes
Mode-based Execute Control (MBEC)  Yes
Intel® Virtualization Technology (VT-x)   Yes
Intel® Virtualization Technology for Directed I/O (VT-d)   Yes
Intel® VT-x with Extended Page Tables (EPT)   Yes
