Core™ i7-12700K 12 (8P+4E) Cores 2.7 - 5.0GHz Turbo, LGA 1700, 190W MTP, OEM Processor

Quantity:
  • SKU: 14660110
  • Manufacturer: INTEL
  • MPN: CM8071504553828
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$452.97
Quantity:
Core™ i7-12700K 12 (8P+4E) Cores 2.7 - 5.0GHz Turbo, LGA 1700, 190W MTP, OEM Processor

12th Gen Intel® Core™ i7-12700K unlocked desktop processor. Featuring Intel® Turbo Boost Max Technology 3.0 and PCIe Gen 4.0 support, unlocked 12th Gen Intel® Core™ desktop processors are optimized for enthusiast gamers and serious creators and help deliver high performance overclocking for an added boost. Thermal solution NOT included in the box. Compatible with 600 series chipset based motherboards 125W.

Essentials
Product Collection12th Generation Intel® Core™ i7 Processors
Code NameProducts formerly Alder Lake
Vertical SegmentDesktop
Processor Numberi7-12700K
StatusLaunched
Launch DateQ4'21
LithographyIntel 7
Use ConditionsPC/Client/Tablet
CPU Specifications
Total Cores12
# of Performance-cores8
# of Efficient-cores4
Total Threads20
Max Turbo Frequency5.00 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency5.00 GHz
Performance-core Max Turbo Frequency4.90 GHz
Efficient-core Max Turbo Frequency3.80 GHz
Performance-core Base Frequency3.60 GHz
Efficient-core Base Frequency2.70 GHz
Cache25 MB Intel® Smart Cache
Total L2 Cache12 MB
Processor Base Power125 W
Maximum Turbo Power190 W
Supplemental Information
Embedded Options AvailableNo
Memory Specifications
Max Memory Size (dependent on memory type)128 GB
Memory TypesUp to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels2
Max Memory Bandwidth76.8 GB/s
Processor Graphics
Processor GraphicsIntel® UHD Graphics 770
Graphics Base Frequency300 MHz
Graphics Max Dynamic Frequency1.50 GHz
Graphics OutputeDP 1.4b | DP 1.4a | HDMI 2.1
Execution Units32
Max Resolution (HDMI)4096 x 2160 @ 60Hz
Max Resolution (DP)7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)5120 x 3200 @ 120Hz
DirectX* Support12
OpenGL* Support4.5
Multi-Format Codec Engines2
Intel® Quick Sync VideoYes
Intel® Clear Video HD TechnologyYes
# of Displays Supported4
Device ID0x4680
OpenCL* Support2.1
Expansion Options
Direct Media Interface (DMI) Revision4.0
Max # of DMI Lanes8
Scalability1S Only
PCI Express Revision5.0 and 4.0
PCI Express ConfigurationsUp to 1x16+4 | 2x8+4
Max # of PCI Express Lanes20
Package Specifications
Sockets SupportedFCLGA1700
Max CPU Configuration1
Thermal Solution SpecificationPCG 2020A
TJUNCTION100°C
Package Size45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator3.0
Intel® Thread DirectorYes
Intel® Deep Learning Boost (Intel® DL Boost)Yes
Intel® Optane™ Memory SupportedYes
Intel® Speed Shift TechnologyYes
Intel® Turbo Boost Max Technology 3.0Yes
Intel® Turbo Boost Technology2.0
Intel® Hyper-Threading TechnologyYes
Intel® Virtualization Technology (VT-x)Yes
Intel® Virtualization Technology for Directed I/O (VT-d)Yes
Intel® VT-x with Extended Page Tables (EPT)Yes
Intel® 64Yes
Instruction Set64-bit
Instruction Set ExtensionsIntel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
Idle StatesYes
Enhanced Intel SpeedStep® TechnologyYes
Thermal Monitoring TechnologiesYes
Intel® Volume Management Device (VMD)Yes
Security & Reliability
Intel® AES New InstructionsYes
Secure KeyYes
Intel® OS GuardYes
Execute Disable BitYes
Intel® Boot GuardYes
Mode-based Execute Control (MBE)Yes
Intel® Control-Flow Enforcement TechnologyYes
