- 3 hotswappable 3.5" bays for HDD quick swap
- Compatible with 2.5" HDDs/SSDs
- Supports standard ATX power supplies
- Slim optical drive bay available
- USB 3.0 in front for easy access
- Sleek aluminum front w/ various color options for HDD handles
- Rackmount or desktop convertible
- Supports 6.0 Gb/s hard drives
Model Number | D-230HB-T |
RoHS Compliance Version | Yes |
Form factor | 2 U |
Standard Drive Bays | 2.5" Drive (internal): 1 3.5" Drive (internal): 1 Hotswap 3.5": 3 Slim 5.25" Optical: 1 |
Hotswap HDD Type: | 3.5" SAS I/II & SATA I/II/III |
Indicators | Power, HDD |
Switches | Power |
Expansion Slots | 4 (Low profile) |
Material of Front Bezel | Aluminum |
Material of Handle | Aluminum |
Material of Main Chassis | SGCC 0.8mm |
Color of Main Chassis | Black |
Front Connector | 2x USB 3.0 |
Motherboard Size | 9.6 x 9.6 (microATX, mini-ITX) |
Cooling Fan | 1x80mm |
Ordering Information (Part Number) |
Black HDD Handle:D-230HB-T Blue HDD Handle:D-230HB-T-BLUE Red HDD Handle:D-230HB-T-RED Silver HDD Handle:D-230HB-T-SILVER |
Dimensions (WxHxD) | 18.98" x 3.48" x 16.33" 482.1 mm x 88.4 mm x 414.8 mm |
Notes | - fits standard ATX power supply with length no more than 140mm. - chassis without HDD cage is: D-230H-T-BPU |
