D-230HN-DT, Silver HDD Handle, 3 x 3.5" Hotswap Bay, No PSU, microATX, Black, 2U Desktop Chassis
The D-230HN-DT-SILVER series are designed with elegance and functionality fit for Home Theater Personal Computer (HTPC). With the advancement of server racks for home, these models are ideal for both rackmount and desktop orientation. With storage capacity up to 8 TB per each bay, the tray-less drive cage maximizes data storage and backup functionality at the same time. These series are ideal platform for HTPC build using popular AMD and Intel processors.
D-230HN-DT-SILVER 2U Compact 3x 3.5" Bay Trayless Hotswap microATX Desktop Chassis
- 3 trayless and hotswappable 3.5" bays for HDD quick swap
- Rackmount or desktop convertible
- Supports standard ATX power supplies
- Slim optical drive bay (12.7mm height) available
- Sleek aluminum front w/ various color options for HDD handles
- USB 3.0 in front for easy access
- Supports 6.0 Gb/s hard drives
Model Number | D-230HN-DT |
RoHS Compliance | Yes |
Form factor | 2 U |
Standard Drive Bays | 2.5" Drive (internal): 1
3.5" Drive (internal): 1 Hotswap 3.5": 3 Slim 5.25" Optical: 1 |
Hotswap HDD Type: | 3.5" SAS I/II & SATA I/II/III |
Indicators | Power, HDD |
Switches | Power |
Expansion Slots | 4 (Low profile) |
Material of Front Bezel | Aluminum |
Material of Handle | Aluminum |
Material of Main Chassis | SGCC 0.8mm |
Color of Main Chassis | Black |
Front Connector | 2x USB 3.0 |
Motherboard Size | 9.6 x 9.6 (microATX, mini-ITX) |
Cooling Fan | 1x80mm |
Ordering Information
(Part Number) |
Black HDD Handle:D-230HN-DT
Blue HDD Handle:D-230HN-DT-BLUE Red HDD Handle:D-230HN-DT-RED Silver HDD Handle:D-230HN-DT-SILVER |
Dimensions (WxHxD) | 18.98" x 3.48" x 14.95"
482.1 mm x 88.4 mm x 379.7 mm |
Notes | - fits standard ATX power supply with length no more than 140mm. |
