D-300L-PFS, Black Bezel, 2x 5.25", 6x 3.5" Drive Bays, No PSU, E-ATX, Black, 3U Chassis
Quantity:
- SKU: 3433093
- Manufacturer: ISTARUSA
- MPN: D-300L-PFS
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$293.24
D-300L-PFS, Black Bezel, 2x 5.25", 6x 3.5" Drive Bays, No PSU, E-ATX, Black, 3U Chassis
The D-300L-PFS incorporate performance and capacity in a 3U form factor. It features two 5.25 and six 3.5 bays for high density storage application. Whether it's web server, database server, D-300L-PFS can accommodate the thermal requirements of dual processor and Raid drive storage needs. The 7 expansion slots support PCI, PCIX, AGP, and PCI-Express add-on cards which enable future upgrades for customized functions and application needs. D-300L-PFS is a cost effective chassis for data and storage server.
D-300L-PFS 3U High Performance Rackmount Chassis Front-mounted ATX Power Supply
- Front Access USB2.0 x2
- 80mm x4 Cooling Fan
- Front Panel with Locks
- Front Mounted ATX Power Supply Design
- Removable Air Filter
- Power and HDD LED
- Power and Alarm Reset Switch
| Model Number | D-300L-PFS |
| RoHS Compliance | Yes |
| Form factor | 3 U |
| Standard Drive Bays | 3.5" Drives: 1
3.5" Drive (internal): 5 5.25" Drives: 2 |
| Indicators | LEDs for Power ON/OFF, HDD, Fan & Alarm |
| Switches | Power ON/OFF, System & Alarm Reset |
| Expansion Slots | 7 |
| Security | Front Bezel |
| Material of Front Bezel | Plastic |
| Material of Handle | SECC Zinc-Coated Steel |
| Material of Main Chassis | 1.2mm SECC Zinc-Coated Steel ( Japan Made ) |
| Color of Front Bezel | Black |
| Color of Main Chassis | Black |
| Front Connector | Front USB 2.0 x 2 Connector |
| Air Filter | Removable & Washable |
| Motherboard Size | 12 x 13 (EATX, ATX, microATX) |
| Cooling Fan | 4x80mm |
| Dimensions (WxHxD) | 19.00" x 5.25" x 27.90"
482.6 mm x 133.3 mm x 708.7 mm |
