D Storm D-300-BLUE, Blue Bezel, 4x 5.25", 3x 3.5" Drive Bays, No PSU, ATX, Black/Blue, 3U Chassis
D Storm D-300-BLUE, Blue Bezel, 4x 5.25", 3x 3.5" Drive Bays, No PSU, ATX, Black/Blue, 3U Chassis
D Storm D-300-BLUE, Blue Bezel, 4x 5.25", 3x 3.5" Drive Bays, No PSU, ATX, Black/Blue, 3U Chassis
D Storm D-300-BLUE, Blue Bezel, 4x 5.25", 3x 3.5" Drive Bays, No PSU, ATX, Black/Blue, 3U Chassis

D Storm D-300-BLUE, Blue Bezel, 4x 5.25", 3x 3.5" Drive Bays, No PSU, ATX, Black/Blue, 3U Chassis

  • SKU: 5520064
  • Manufacturer: ISTARUSA
  • MPN: D-300-BLUE
  • Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Price
$261.04
Quantity:
D Storm D-300-BLUE, Blue Bezel, 4x 5.25", 3x 3.5" Drive Bays, No PSU, ATX, Black/Blue, 3U Chassis
The 3U industrial rackmount chassis D Storm D-300-BLUE. Optional BPU series enable hot-swappable storage and RAID configuration. D-300 backplane supports 7 full-length add-on cards. Optional Aluminum Body reduces total chassis weight and also provides enhanced thermal cooling solution provide your system with maximum flexibility and performance.

D-300-BLUE 3U Compact Stylish Rackmount Chassis

  • Patented Aluminum Front Panel with Locks,Taiwan: 200281 / 190240 , China: 2L01259648.5
  • Front Access USB2.0 x2
  • 60mm x1 Cooling Fan
  • Removable Air Filter
  • Power and HDD LED
  • Power and Alarm Reset Switch
  • Optional Aluminum Chassis (model number D-300A)
Model Number D-300-BLUE
RoHS Compliance Yes
Form factor 3 U
Standard Drive Bays 3.5" Drives: 2
3.5" Drive (internal): 1
5.25" Drives: 4
Indicators Power, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 )
Switches Power, Reset
Supported PSU Type 1U, 2U
Expansion Slots 7
Security Front Bezel Key Lock
Material of Front Bezel Aluminum alloy
Material of Handle SECC Zinc-Coated Steel
Material of Main Chassis 1.2mm SECC Zinc-Coated Steel (Japan Made)
Color of Front Bezel Blue
Color of Main Chassis Black
Front Connector 2x USB 2.0
Air Filter Removable & Washable
Motherboard Size 12 x 9.6 (ATX, microATX)
Cooling Fan 1x60mm
Optional Fan: 60mm x1, 80mm x3 (bracket DD-FANGUARD-8 required)
Ordering Information
(Part Number)		 Red Bezel:D-300-BLUE
Dimensions (WxHxD) 19.00" x 5.25" x 20.80"
482.6 mm x 133.3 mm x 528.3 mm
Notes - supports power supply length up to 250mm when hotswap cages installed in the front.
- optional Aluminum body model number D-300A.
