Model Number | D-407L-50R8PD2 |
RoHS Compliance Version | Yes |
Form factor | 4 U |
Standard Drive Bays | 3.5" Drives: 1
3.5" Drive (internal): 1 5.25" Drives: 7 |
Indicators | Power, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 ) |
Switches | Power, Reset |
Supported PSU Type | PS2, Mini Redundant |
Expansion Slots | 7 |
Security | Front Bezel Key Lock |
Material of Front Bezel | Aluminum alloy |
Material of Handle | SECC Zinc-Coated Steel |
Material of Main Chassis | 1.2mm SECC Zinc-Coated Steel (Japan Made) |
Color of Front Bezel | Black |
Color of Main Chassis | Black |
Front Connector | 2x USB 2.0 |
Air Filter | Removable & Washable |
Motherboard Size | 12 x 13 (EATX, ATX, microATX) |
Cooling Fan | 1x80mm, 3x120mm |
Optional Fan: | 80mm x1 |
Ordering Information
(Part Number) |
Black Bezel:D-407L-50R8PD2
Blue Bezel:D-407L-BL-50R8PD2 Red Bezel:D-407L-RD-50R8PD2 Silver Bezel:D-407L-SL-50R8PD2 |
Dimensions (WxHxD) | 19.00" x 7.00" x 27.90"
482.6 mm x 177.8 mm x 708.7 mm |
