Screen display spec | |
model | 24.6mm(W) * 131.7(H) * 205.3(L) |
Display size | 8" Color TFT-LCD |
Colors | 16.7M |
Resolution | 1280*800 |
Response Time | 30ms(Typ.) |
Brightness | 300cd/m2(Typ.) |
Contrast Ratio | 1000(Typ.) |
I/O | MINI-HDMI*1(Video Signal) TYPE-C*1 |
Refresh Rate(max.) | 60Hz |
Working Temperture | 0-50°C |
Product Specification | |
Model | D41 MESH SCREEN Black |
Dimension | 205mm (W) * 392mm(H) *440mm(D) (Vol: 35.4L)*Depth does not include the PCI brackets outside the chassis, height does not include case stand205mm (W) * 407mm(H) * 452mm(D) (overall size) |
Material | 0.6mm+0.7mm steel panel |
Drive Bay | 2.5" SSD*3+3.5" HDD*2 |
Motherboard | ATX / M-ATX |
PCI expansion slots | 7 |
Front I/O | USB3.2 Gen 2 Type-C*1 / USB3.0*1/Audio & Mic*1 |
Power supply support | ATX |
CPU cooler support | 168mm |
Graphics card support | 330-400mm |
Fan mounting position | Top 120mm*3 or 140mm*2 Rear 120*1mm Bottom 120mm*3 or 140mm*2 Front 120mm*1 |
Radiator support | Top 240/280/360*1 Rear 120*1 Bottom 240/360*1 |
Weight | Net 6.78KG |
