Define 7, No PSU, E-ATX, Black Mid Tower Case
Quantity:
- SKU: 13261846
- Manufacturer: Fractal Design
- MPN: FD-C-DEF7A-01
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$197.42
Define 7, No PSU, E-ATX, Black Mid Tower Case
Fractal Design Define 7 (FD-C-DEF7A-01). The Define 7 is the latest pinnacle of the renowned Define series, setting a new standard for what you should expect from a mid-tower case when it comes to modularity, flexibility and ease of use.
- New chassis design opens up to fully expose the case interior
- Anodized aluminum front panel with reversible dual-handed hinges
- Multibracket converts unused fan positions to HDD, SSD or pump mounts
| Specifications | |
| 3.5"/2.5" Universal drive brackets | 6 included, 14 positions total |
| Dedicated 2.5" drive brackets | 2 trays included, 4 positions total |
| 5.25” drive mounts | 1 |
| Expansion slots | 7 + 2 |
| Front ports | 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button |
| Total fan mounts | 9 x 120/140 mm |
| Front fan | 3 x 120/140 mm (2 x Dynamic X2 GP-14 included) |
| Top fan | 3 x 120/140 mm |
| Rear fan | 1 x 120/140 mm (1 x Dynamic X2 GP-14 included) |
| Bottom fan | 2 x 120/140 mm |
| Dust filters | Top, 2 x front, full length bottom |
| Fixed velcro straps | Yes |
| Cable routing grommets | Yes |
| Captive thumbscrews | HDD brackets, SSD brackets, PSU bracket |
| Left side panel | Industrial sound-damped steel |
| Right side panel | Industrial sound-damped steel |
| Compatibility | |
| Motherboard compatibility | E-ATX (max 285 mm) / ATX / mATX / mITX |
| Power supply type | ATX |
| PSU max length | 250 mm (with HDD cage installed) |
| GPU max length | Storage layout: 315 mm - Open layout: 491 mm (467 mm w/ front fan) |
| CPU cooler max height | 185 mm |
| Front radiator | Up to 360/280 mm |
| Top radiator | Up to 360/420 mm |
| Rear radiator | 120 mm |
| Bottom radiator | Up to 240/280 mm |
| Cable routing space | 30 mm |
| Dimensions | |
| Case dimensions (LxWxH) | 547 x 240 x 475 mm |
| Case dimensions w/o feet/protrusions/screws | 533 x 240 x 451 mm |
| Package dimensions (LxWxH) | 558 x 363 x 641 mm |
| Net weight | 13.49 kg |
| Package weight | 15.98 kg |
| Other | |
| Package contents | Define 7 case. Accessory box. User manual. Ventilated top. 4 x HDD/SSD trays (for a total of 6) |
| EAN | Black - 7340172702191 |
| UPC | Black - 843276102197 |
| JAN | Black - 4537694275842 |
| Product code | Black - FD-C-DEF7A-01 |
