Define 7 XL TG Dark Tint, Tempered Glass, No PSU, E-ATX, Black, Full Tower Case
- SKU: 13258494
- Manufacturer: Fractal Design
- MPN: FD-C-DEF7X-03
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Price
$278.79
- Use the Open Layout for more headroom and gargantuan water-cooling with radiators up to 480 mm in front or top and 280 mm in the base
- Spacious, extensively adaptable dual-layout interior easily accommodates large motherboards up to E-ATX and SSI-EEB
- Two 5.25” ODD bays can be converted to an additional front fan mount with filtered louver covering
- Ventilated PSU shroud with two-part removable cover
- Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans
| Specifications | |
|---|---|
| 3.5"/2.5" Universal drive brackets | 6 + 2 included, 18 positions total |
| Dedicated 2.5" drive brackets | 2 included, 5 positions total |
| 5.25” drive mounts | 2 |
| Expansion slots | 9 + 3 |
| Front ports | 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button |
| Total fan mounts | 11 x 120 mm or 9 x 140 mm |
| Front fan | 4 x 120 mm or 3 x 140 mm, (2 x Dynamic X2 GP-14 included) |
| Top fan | 4 x 120 mm or 3 x 140 mm |
| Rear fan | 1 x 120/140 mm, (1 x Dynamic X2 GP-14 included) |
| Bottom fan | 2 x 120/140 mm |
| Dust filters | Top, 2 x Front, Bottom + PSU |
| Fixed velcro straps | Yes |
| Cable routing grommets | Yes |
| Captive thumbscrews | HDD brackets, SSD brackets, PSU bracket |
| Left side panel | Tempered glass |
| Right side panel | Industrial sound-damped steel |
| Compatibility | |
| Motherboard compatibility | E-ATX / ATX / mATX / mITX / EE-ATX / SSI-CEB / SSI-EEB |
| Power supply type | ATX |
| PSU max length | 250 mm (both HDD cages installed) |
| GPU max length | Storage layout: 359 mm - Open layout: 549 mm (524 mm w/ front fan) |
| CPU cooler max height | 185 mm |
| Front radiator | Up to 480/420 mm |
| Top radiator | Up to 480/420 mm |
| Rear radiator | 120 mm |
| Bottom radiator | Up to 240/280 mm |
| Cable routing space | 30 mm |
| Dimensions | |
| Case dimensions (LxWxH) | 604 x 240 x 566 mm |
| Case dimensions w/o feet/protrusions/screws | 590 x 240 x 548 mm |
| Package dimensions (LxWxH) | 646 x 357 x 708 mm |
| Net weight | 16.64 kg |
| Package weight | 18.84 kg |
| Other | |
| Package contents | Define 7 XL - Accessory box - User manual - Ventilated top panel - ODD bracket - ODD bay cover - 2 x HDD/SSD trays |
| EAN | 7340172702061 |
| UPC | 843276102067 |
| JAN | 4537694275385 |
| Product code | FD-C-DEF7X-03 |
