DeskMini H470, Intel® H470 Chipset, 2x DDR4 SO-DIMM, 1x M.2, 2x 2.5" HDD/SSD, 120W Power Adapter, Mini PC Barebone
Quantity:
- SKU: 13828665
- Manufacturer: ASROCK
- MPN: DESKMINI H470W
- Availability: CONTACT US
Starting At
$160.01
- Supports Intel® 10th Gen LGA1200 processors, up to 65W
- Dual DDR4-2933MHz SO-DIMMs, up to 64GB
- Multi Video Outputs: 2 x DisplayPort, HDMI & D-Sub
- 1 x Alternate Mode USB Type-C
- 1 x USB 3.2 Gen1 Type-C port
- 1 x Ultra M.2 PCIe Gen3 x4 Slot
- 2 x 2.5" HDD/SSD Tray with RAID 0/1
- 1 x M.2 (2230) Wi-Fi Slot
| CPU | Supports Intel® 10th Gen LGA1200 Processors (Max. TDP 65W) |
| Cooler | Supports Intel® CPU Cooler (Max. Height ≦ 46mm) |
| Memory | Supports 2 x SO-DIMM DDR4-2933MHz, Max. 64GB (non-ECC) |
| Chipset | Intel® H470 |
| Graphics |
- HDMI(4K@30Hz) - DisplayPort1.4 - DisplayPort 1.4 (with USB Type-C Alt Mode) - D-Sub *Supports up to 3 displays simultaneously
|
| Audio | 1 x Head Phone with MIC Jack, 1 x MIC-In (Realtek ALC233) |
| Front USB | 1 x USB 3.2 Gen1 Type-C, 1 x USB 3.2 Gen2 Type-A |
| Rear USB |
1 x USB 3.2 Gen1 Type-C, 4 x USB 3.2 Gen1 Type-A *Rear side supports USB Type-C Alt Mode
|
| Storage |
2 x SATA 6Gb 2.5-inch 7mm/9.5mm Hard Drive (RAID 0/1) 1 x Ultra M.2 Socket, support type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)*
*Supports Intel® Optane Technology
Supports NVMe SSD as boot disks |
| LAN | Gigabit LAN (Intel® I219V) |
| WLAN | 1 x M.2 (key E 2230) Slot for Wi-Fi + BT Module |
| Connectors |
1 x USB 2.0 Header 1 x Front Panel Header 2 x 4-Pin fan connectors (CPU, SYS) 1 x DC-In Jack (Supports 19V Power Adapters) 1 x Internal Speaker Header (4-Pin) 1 x Chassis Intrusion Header (2-Pin) 1 x Audio Header (4-Pin) |
| Accessory |
2 x SATA Data with Power Cable 1 x 120W/19V adapter 1 x Screws Pack 1 x Intel® AC-3168 Wi-Fi Kit |
| Dimension | 155 x 155 x 80 mm (1.92L) |
