E Storm Rugged E-4140, 3x 5.25" and 2x 3.5" Drive Bays, No PSU, Passive backplane/ Single board, Black, 4U Chassis
Quantity:
- SKU: 5906468
- Manufacturer: ISTARUSA
- MPN: E-4140
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$305.89
E Storm Rugged E-4140, 3x 5.25" and 2x 3.5" Drive Bays, No PSU, Passive backplane/ Single board, Black, 4U Chassis
Introducing the E-4140 rugged rackmount chassis, ultra strong and compact for rugged environment and critical application. The E-4140 is designed to perform military operations or industrial applications that require spill proof and high impact strength enclosure. Exceptional designed shock absorbing drive cage, cooling ventilation system, and total depth of 17.8 is the most versatile and tough rackmount chassis on the market.
- 1.6mm steel body chassis
- Front access USB2.0 x1
- 120mm x1 cooling fan
- Removable air filter
- Spill-proof bezel with lock
- Shock absorbing drive cage
- 14 slot passive backplate
- Fan and temperature monitor
- Compact 17.8" depth
| Model Number | E-4140 |
| RoHS Compliance Version | Yes |
| Form factor | 4 U |
| Standard Drive Bays | 3.5" Drives: 1
3.5" Drive (internal): 1 5.25" Drives: 3 |
| Indicators | LEDs for Power ON/OFF, HDD, Fan & Alarm |
| Switches | Power ON/OFF, System & Alarm Reset |
| Expansion Slots | 14 |
| Security | Front Bezel |
| Material of Front Bezel | 1.6mm SECC Zinc-Coated Steel |
| Material of Handle | 1.6mm SECC Zinc-Coated Steel |
| Material of Main Chassis | 1.6mm SECC Zinc-Coated Steel |
| Color of Front Bezel | Black |
| Color of Main Chassis | Black |
| Front Connector | Front USB 2.0 x 1 Connector |
| Air Filter | Removable & Washable |
| Motherboard Size | Passive backplane/ Single board |
| Cooling Fan | 1x120mm |
| Optional Fan: | 1x80mm Blower |
| Dimensions (WxHxD) | 19.00" x 7.00" x 17.80"
482.6 mm x 177.8 mm x 452.1 mm |
