Wi-Fi Technology |
AC2200 MU-MIMO Tri-band Gigabit, 400+867+867 Mbps |
Key Features |
- Tri-Band (5 GHz + 5GHz + 2.4 GHz), 2x2 AC
- MU-MIMO/ Seamless Roaming
- Auto Firmware Update
- Quad-Core CPU+ 3 offload Processors
- Advanced SPI+ DoS protection Security
- Advanced Beamforming+ Technology
- Airtime Fairness
- USB 3.0 Port
- Smart Connect Band Steering
- 4 Adjustable Antennas+ 6 High Power Amplifiers
- Smart Wi-Fi Cloud Management
|
Network Standards |
- 802.11b
- 802.11a/g
- 802.11n
- 802.11ac
|
Wi-Fi Speed |
AC2200 (N400 + AC867 + AC867) |
Wi-Fi Bands |
2.4 and 5 GHz(2x) (simultaneous tri-band) |
Wi-Fi Range |
Medium Household |
Number of Ethernet Ports |
- 1x Gigabit WAN port
- 4x Gigabit LAN ports
|
Other Ports |
|
Antennas |
4x external adjustable antennas |
Processor |
716Mhz Quad-core |
Memory |
RAM: 256MB; Flash: 256MB |
LEDs |
Illuminated Linksys logo , Wi-Fi Protected Setup, Internet connection, Network cable connection to Internet port. |
Wireless Encryption |
64/128-bit WEP, WPA2 Personal, WPA2 Enterprise |
Operation Modes |
- Wireless Router
- Access Point(Wired Bridge)
- Wireless Bridge
- Wireless Repeater
|
Storage File System Support |
|
Easy Setup |
Browser-based Setup |
Minimum System Requirements |
Latest versions of Google ChromeTM, Firefox®, Safari® (for Mac® and iPad®), Microsoft Edge and Internet Explorer® version 8 and newer |
Dimensions (LxWxH) |
213.7mmX161.8mmx54.8mm (without Antenna) |
Weight |
608 g |
Security Features |
- WPA/WPA2
- 128 bit AES link encryption
|
Regulatory Compliance |
FCC class B |
Other Certifications |
Wi-Fi |
Power Supply |
Input: 100-240V ~ 50-60Hz; Output: 12V, 2A |
