General | |
Function | MI |
Style Number | EMI3DJ35GJR78A1 |
Part Number | EMI319-10 |
Product Code | 50005 |
Availability | Top Sellers 0-2 week lead time |
Physical | |
Dimensions (H x W x D, inches) | Box: 77.6 X 7.7 X 9.3 Unit: 66.5 x 2.05 x 2.1 |
Mounting Style | Vertical - (easily installs in rear of standard 19-inch rack) |
Form factor | 0U |
Input | |
Max kW | 17.3 |
Plug |
(1) IEC60309 532P6
|
Cable Length (ft) | 10 |
Voltage | 240/415V |
Current | 24A |
Current Monitoring | Input, Section, +/- 1% |
Phase | Three Phase |
Frequency | 50-60 HZ |
Output | |
Outlets |
(24) IEC-320-C13
(6) IEC-320-C19
|
Circuit Breakers | (6) 20A |
Outlet Control | No |
Local Switches | No |
Protection & Filtering | |
Spike/Surge Suppression | None |
EMI/RFI Filter | None |
Control & Interface | |
Configuration file for eNMC replacement | Download |
Environmental Interface | Optional EMP001 |
Serial Interface | RS232 |
Ethernet Interface | 10/100 Ethernet |
Voltage Monitoring | Yes |
Standards | |
Approvals | UL Listed File # E94081 |
