EX500-B, 80 Plus Bronze 500W, No Modular, SFX Power Supply
EX500-B, 80 Plus Bronze 500W, No Modular, SFX Power Supply
EX500-B, 80 Plus Bronze 500W, No Modular, SFX Power Supply
EX500-B, 80 Plus Bronze 500W, No Modular, SFX Power Supply
EX500-B, 80 Plus Bronze 500W, No Modular, SFX Power Supply
EX500-B, 80 Plus Bronze 500W, No Modular, SFX Power Supply

EX500-B, 80 Plus Bronze 500W, No Modular, SFX Power Supply

  • SKU: 15146487
  • Manufacturer: SILVERSTONE
  • MPN: EX500-B
  • Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Price
$100.05
$3.23/mo* with bread pay
Quantity:
  • Supports standard SFX form factor and ATX via included bracket
  • 500W 24/7 continuous power output with 40? operating temperature
  • Silent running 92 mm fan with 18dBA minimum
  • Japanese primary capacitor
  • High efficiency with 80 PLUS Bronze certification
  • Class-leading single +12V rail
  • PCIe 8-Pin and PCIe 6-Pin connectors support
Product No. SST-EX500-B
Color Black (lead-free paint)
Power density 630W per liter
Combined +3.3V & +5V 120W
Input Voltage 90 ~ 264 Vrms
PFC Active PFC(PF>0.9 at Full Load)
MTBF 100,000 hours
Protection Over Current Protection

Over Power Protection

Over Voltage Protection

Short Circuit Protection

Over Temperature Protection
Cooling System Silent 92mm fan
Certification 80 PLUS Bronze
Dimension 125 mm (W) x 63.5 mm (H) x 100 mm (D)
Model (safety certification) SST-SX0500FCBR-A
Max. DC Output 500W
Load Range
Output +3.3V +5V +12V +5VSB -12V
Max.(Amps) 20A 20A 41.66A 2.5A 0.3A
Min.(Amps) 0.0A 0.0A 0.0A 0.0A 0.0A
Range (%) ±5% ±5% ±5% ±5% ±10%
Line Reg.(%) ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p) 50mV 50mV 120mV 50mV 120mV
Combined +12V 499.2W
Input Frequency Range 47Hz ~ 63Hz
Efficiency 82% ~ 85% at 20% ~ 100% loading
Connectors 1 x 24 / 20-Pin motherboard connector

1 x 8-Pin EPS / ATX 12V connector

1 x 8 / 4-Pin EPS / ATX 12V connector

2 x 8 / 6-Pin PCIe connectors

3 x SATA connectors

2 x 4-Pin Peripheral connectors

1 x 4-Pin Floppy connector
Noise Level 18 dBA minimum
Form factor SFX
Weight 1.02 kg
