Economy, Network Server Surge Protector, 1U Rack-Mount, 14-Outlet, 15-ft. Cord, 3000 Joules, 1800W, 120V AC, Black

Quantity:
  • SKU: 305682
  • Manufacturer: TRIPP LITE
  • MPN: DRS-1215
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$101.07
Quantity:
Economy, Network Server Surge Protector, 1U Rack-Mount, 14-Outlet, 15-ft. Cord, 3000 Joules, 1800W, 120V AC, Black

Tripp Lite's DRS-1215 offers surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Includes 14 outlets (6 front/8 rear), 15 ft AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LED indicates surge protection status.

  • 3000 joules AC surge suppression with EMI/RFI filtering
  • 14 NEMA 5-15R output receptacles (6 front/8 rear)
  • 15 foot AC cord with NEMA 5-15P straight-in plug connection
  • Diagnostic LED confirms suppressor operation
  • Lighted power switch confirms power on/off status
  • Snap-in switch guard prevents accidental turn off
  • 15 amp capacity with circuit breaker
  • 120V AC, 50/60Hz electrical compatibility
Output
Frequency Compatibility 50 / 60 Hz
Output Receptacles (14) 5-15R
Output (Watts) 1800
Circuit Breaker (amps) 15
Input
Nominal Input Voltage(s) Supported 120V AC
Recommended Electrical Service 120V (110-125V)
Input Connection Type NEMA 5-15P input plug
Input Cord Length (ft.) 15
Voltage Compatibility (VAC) 120
Maximum Surge Amps 120000
Physical
Shipping Dimensions (hwd / in.) 2.25 x 20.5 x 9.25
Shipping Weight (lbs.) 5.5
Unit Dimensions (hwd / in.) 1.75 x 17.5 x 4
Unit Weight (lbs.) 4.6
Material of Construction Metal
Included Mounting Accessories Included mounting flanges are pre-installed for 1U rackmount installation and can be re-configured to support a variety of mounting options
Housing Color Black
Receptacle Color Black
Color (AC Line Cord) Black
Form Factors Supported 1U rackmount, 0U vertical rackmount, wallmount and under-counter mounting supported - detachable flanges can be re-configured to support a variety of additional mounting options
Outlets Measurement (Center to Center) Distance between front outlets = 38.9mm; Distance between rear outlets = 38.9mm
