- Tempered glass side panel with magnetic locking mechanism, hardware installation and upgrades made convenient
- Dual 360mm liquid cooling radiator support, perfectly meeting the cooling requirements for high-end CPUs and GPUs
- Unobstructed airflow performance with support for up to 11 cooling fans
- Supports high-end graphics cards of up to 390mm, in either vertical or horizontal orientation
Model No. | SST- FAB2-BG (Black,Tempered glass) |
Material | Steel, plastic, tempered glass |
Motherboard | E-ATX (12" x 13"), ATX (12" x 11"), Micro-ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7") |
Drive bay | |
Internal |
3.5" / 2.5" x 1 3.5" x 1 2.5" x 2 |
Cooling system | |
Front | 120mm x 3 / 140mm x 3 |
Rear | 120mm x 1 |
Top | 120mm x 3 / 140mm x 2 |
Side | 120mm x 2 |
Radiator support | |
Front | 120mm / 140mm / 240mm / 280mm / 360mm |
Rear | 120mm |
Top | 120mm / 140mm / 240mm / 280mm / 360mm |
Side | 120mm / 240mm |
Limitation of CPU cooler | 170mm |
Expansion slot | 7 |
Limitation of expansion card | 390mm |
Power supply | Standard PS2 (ATX) |
Limitation of PSU | 220mm |
Front I/O port |
USB 3.0 x 2 Audio x 1 Mic x 1 |
Dimension |
220mm (W), x 490mm (H), x 470.4mm (D), 50.8 liters 8.7" (W), x 19.21" (H), x 18.54" (D), 50.8 liters |
Net weight | 6.6 kg |
