- 600+600W 24 hours and well-working performance at 50°C °C fully continuous power output
- 1+1 redundant configuration
- Japanese electrolytic capacitors
- Hot swappable design
- Convenient pull-out handle bars
- Industry-leading reliability
Product No. | SST-GM600-S | ||||
Model (safety certification) | SST-MR0600FCSI-A | ||||
Color | Silver | ||||
Max. DC Output | 600W | ||||
Power density | 467W per liter | ||||
Combined +3.3V & +5V | 180W | ||||
Combined +12V | 588W | ||||
Input Voltage | 90 ~ 264V | ||||
Input Frequency Range | 47Hz ~ 63Hz | ||||
PFC | Active PFC (PF>0.9 at full load) | ||||
Efficiency | ≥85% & <87% overall efficiency with a single modular power supply | ||||
MTBF | 100,000 hours | ||||
Operating temperature | 0°C ~ 50°C | ||||
Protection |
Over current protection Over voltage protection Over temperature protection Short circuit protection |
||||
Connectors |
1 x 24 / 20-Pin motherboard connector 2 x 8 / 4-Pin EPS / ATX 12V connectors 2 x 8 / 6-Pin PCIe connectors 3 x SATA connectors 6 x 4-Pin Peripheral connectors 1 x 4-Pin Floppy connector 1 x 2-Pin +5V TTL signal connector |
||||
Cooling System | 40mm DC fans | ||||
Noise Level | 51 dBA | ||||
Certification | Cybenetics Silver | ||||
Form factor | PS/2 mini redundant | ||||
Dimension |
150mm (W) x 86mm (H) x 199mm (D) 5.91" (W) x 3.39" (H) x 7.83" (D) (Housing without bracket) 150mm (W) x 86mm (H) x 212mm (D) 5.91" (W) x 3.39" (H) x 8.35" (D) (Housing with bracket, without handle) 140mm (W) x 40mm (H) x 175mm (D) 5.51" (W) x 1.57" (H) x 6.89" (D) (Module only without handle) |
||||
Weight | 4.1 kg | ||||
Load Range | |||||
Output | +3.3V | +5V | +12V | +5VSB | -12V |
Max.(Amps) | 25A | 25A | 49A | 3.5A | 0.8A |
Min.(Amps) | 1.0A | 1.0A | 1.0A | 0.1A | 0A |
Range (%) | ±5% | ±5% | ±5% | ±5% | ±10% |
Line Reg.(%) | ±1% | ±1% | ±1% | ±1% | ±1% |
Ripple(mVp-p) | 50mV | 50mV | 120mV | 50mV | 120mV |
LED indicator | |||||
Power Supply Condition | Power System Status | Module Status | |||
No AC power to all PSU | OFF | OFF | OFF | |||
AC present / only standby output on | Red | Orange | OFF | |||
Power supply DC output ON and OK | Green | Green | Orange | |||
Power supply failure | Red / OFF | Green Blinking | OFF |
