Grandia Series SST-GD08B, No PSU, E-ATX, Black, HTPC Case

SKU: 6888199

Manufacturer: SILVERSTONE

MPN: SST-GD08B

Availability: Unknown


Price: $175.30
or as low as $6/month
Quantity:

The introduction of Grandia GD07 and GD08 cases from SilverStone ushers in a new era of home theater computing like never before. For the first time, the power and storage capacity of a server can now be neatly stowed beautifully and quietly in a home theater environment. Completely reengineered to fully utilize all available spaces, the Grandia GD08 can accommodate an incredible amount of drives (up to twelve) and high-end components (graphics cards up to 13.6 inches long) with minimal sacrifices. It is even possible to fit SSI EEB (12” x 13”) extended ATX motherboards in the GD07 despite maintaining an exterior dimension similar to SilverStone’s previous generation full-size HTPC cases. With a wealth of lessons learned from building the best performing tower cases in the last several years, SilverStone engineers upgraded GD08’s cooling performance tremendously with up to five 120mm fan options. And to make sure owners can easily maintain their cases’ cooling ability over time with the lowest noise possible, custom designed removable filters surround the case for positive pressure to work effectively and quietly. To complement the tremendous new design, the GD08 is built with the thickest aluminum front panel of any SilverStone case with a styling that pays homage to the most popular HTPC case ever made, the Lascala LC17. For HTPC enthusiasts all over the world, this case is truly a dream come true!

  • Positive air pressure design for excellent cooling/quietness and dust-prevention
  • Support expansion cards up to 13.6 inches
  • Supports Extended ATX motherboard
  • Quick access filters to prevent dust buildup
  • Aluminum front panel with premium styling
  • LED indicator with adjustable brightness
  • Impressive storage capacity of up to twelve drive bays

Model No.

SST-GD08B(Black)

Material

Aluminum front panel, SECC body

Motherboard

SSI-EEB, SSI-CEB, Extended ATX, ATX, Micro-ATX *1

Multimedia

--

Drive Bay

External 5.25" x 2 (support optical drive only)
--
Internal 3.5" x8, 2.5” x2

Cooling System

Front --
Rear 2 x 80mm fan slot
Side 1 x 120mm intake fans, 900rpm, 18dBA
1 x 120mm fan slot
Top oversized vents
Bottom 2 x 120mm intake fans, 900rpm, 18dBA
(backwards compatible with 1 x 120mm fan + 3 x 80mm fans, or 6 x 60mm fans)
Internal --

Expansion Slot

7+1

Front I/O Port

USB 3.0 x 2
audio x 1
MIC x 1

Power Supply

Support standard PS2(ATX) up to 220mm, recommend depth is under 180mm *2

Operating system support

--

Expansion Card

Support graphic cards up to 13.6 inches, width restriction-5.25"

Limitation of CPU cooler

138mm

Limitation of PSU

220mm

Net Weight

7kg

Dimension

440mm(W) x 175mm(H) x 425mm(D), 32.7 liters

Extra

Support Kensington lock

Support VESA Mount

--
