H570 TG Snow Tempered Glass, No PSU, E-ATX, White, Mid Tower Case
Quantity:
- SKU: 14959150
- Manufacturer: THERMALTAKE
- MPN: CA-1T9-00M6WN-00
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$158.26
H570 TG Snow Tempered Glass, No PSU, E-ATX, White, Mid Tower Case
H570 TG Snow is a mid-tower chassis that comes with three preinstalled 120mm ARGB front fans, one preinstalled 120mm standard rear fan, and can support up to E-ATX (12" x 13") Motherboards.
| P/N | CA-1T9-00M6WN-00 |
| Series | H Series |
| Model | H570 TG Snow |
| Case Type | Mid Tower |
| Dimension (H x W x D) | 487 x 216 x 463.6 mm (19.2 x 8.5 x 18.3 inch) |
| Net Weight | 7.65 kg / 16.87 lbs. |
| Side Panel | 4 mm Tempered Glass x 1 |
| Color | White |
| Material | SPCC |
| Cooling System | Front(intake): 120 x 120 x 25 mm ARGB fan (1000rpm, 27.2 dBA) x 3 Rear(exhaust): 120 x 120 x 25 mm standard fan (1100rpm, 22.5 dBA) x 1 |
| Drive Bays -Accessible -Hidden |
2 x 3.5”, 2 x 2.5” or 4 x 2.5” |
| Expansion Slots | 7 |
| Motherboards | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13”(E-ATX) |
| I/O Port | USB 3.0 x 1, USB 2.0 x 2, HD Audio x 1, LED button x 1 |
| PSU | Standard PS2 PSU (optional) |
| Fan Support | Front: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm 2 x 200mm, 1 x 200mm Top: 3 x 120mm, 2 x 120mm, 1 x 120mm, 2 x 140mm, 1 x 140mm Rear: 1 x 120mm |
| Radiator Support | Front: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Top: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Rear: 1 x 120mm |
| Clearance | CPU cooler height limitation: 160mm VGA length limitation: 375mm PSU length limitation: 180mm |
