| General |
| Enclosure Type |
Dual-chamber ATX case |
| Motherboard Support |
ATX, Micro-ATX, Mini-ITX |
| Rear-Connecting Motherboard Support |
Yes (ATX) |
| Power Supply Type |
ATX |
| Materials |
Steel, tempered glass |
| Dimensions |
| Dimensions (H x W x D) |
448 x 292 x 420 mm (17.6 x 11.5 x 16.5 in) |
| Volume |
55 L |
| Weight |
9.3 kg (20.5 lb) |
| Clearance |
| CPU Cooler Height |
Up to 165 mm (6.5 in) |
| GPU Length |
Up to 390 mm (with 30 mm front-right fan) |
| PSU Length |
Up to 200 mm (7.9 in) |
| Cable Routing Space |
Up to 90 mm (3.5 in) |
| Front-Right Fan Thickness |
Up to 30 mm (without limiting GPU length) |
| Top Radiator + Fan Thickness |
Up to 67 mm (2.6 in) |
| Front I/O |
| USB 3.2 Type-A |
2 |
| USB 3.2 Gen 2x2 Type-C |
1 |
| Headset Jack |
1 |
| Expansion & Drives |
| Expansion Slots |
7 |
| 2.5" Drive Bays |
2 |
| 3.5" Drive Bays |
1 |
| Cooling Support |
| Front-Right Fans |
3 x 120 mm |
| Top Fans |
3 x 120 mm |
| Bottom Fans |
3 x 120 mm |
| Rear Fan |
1 x 120 mm |
| Top Radiator |
Up to 360 mm (Up to 400 mm) |
| Rear Radiator |
Up to 120 mm |
| Included Fan Specs |
| Model |
F360 RGB Reverse / F120 RGB |
| Quantity |
2 / 1 |
| Speed |
2,200 ± 220 RPM / 2,400 ± 240 RPM |
| Airflow |
62.14 CFM / 70.67 CFM |
| Static Pressure |
2.7 mmH2O / 3.7 mmH2O |
| Noise Level |
34.39 dBA / 33.05 dBA |
| Fan Connector |
8-pin (4-pin PWM and NZXT RGB combo) / 4-pin |
| Control Hub |
| Fan Channels |
2 x NZXT 8-pin (PWM only) / 1 x 4-pin PWM (DC+PWM control) |
| RGB Channels |
2 x NZXT 8-pin / 1 x NZXT RGB |
| Max LED Support |
Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to
5 NZXT devices.
|
| System Requirements |
USB 2.0 Internal Header / SATA Power |
| Cable Management |
| Fixed Velcro Straps |
Yes |
| Included Zip Ties |
Yes |
| Product Info |
| Warranty |
2 years |
| Model Number |
CC-H62FW-P1 (White) / CC-H62FB-P1 (Black) |
| UPC |
810074846905 (White) / 810074846899 (Black) |
| EAN |
5056547209364 (White) / 5056547209357 (Black) |
