H7 Quad Lumi, 145mm Height, 160W TDP, Copper/Nickel CPU Cooler

  • SKU: 13591712
  • Manufacturer: CRYORIG
  • Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
H7 Quad Lumi, 145mm Height, 160W TDP, Copper/Nickel CPU Cooler

CRYORIG H7 Quad Lumi (CR-H7 QUAD LUMI). Enhanced Efficiency with Hive Fin Technology. Featuring CRYORIG’s proprietary Hive Fin™ technology, the H7 Quad Lumi gains the benefit of faster hot air exhaust speeds and air turbulence reduction, so air passes through further and is expelled faster!

Heatsink Specification
Dimension ( with fan ) L98 mm x W123 mm x H145 mm
Weight ( with fan ) 713 g
Weight ( without fan ) 585 g
Heat pipes 6mm heatpipe x 4 units
Fin T = 0.4 mm ; Gap = 2.2 mm
Fin Pcs 40 pcs
Copper Base C1100 Pure copper nickel plated
RAM Height Limit Limitless
TDP 160 W
Fan Specification
Model QF120 Black Balance
Dimension L120 mm x W120 mm x H25.4 mm
Weight 128 g
Rated Speed 330 ~ 1600 RPM ±10 %
Noise Level 10 ~ 25 dBA
Air Flow 59 CFM
Air Pressure 1.65 mmH2O
Ampere 0.25 A
Light White
Motherboard Compatibility
Intel 2066, 2011(-3), 1150, 1151, 1155, 1156, 1200
AMD FM1, FM2/+, AM2/+, AM3/+, AM4
What's In The Box

H7 Quad Lumi x 1
X-Bar™ Backplate x 1
Hexagon Pillars x 4
Intel Mounting Bar x 2
AM4 Mounting Plate x 1
Thumb Screw Caps x 4
Screw Pillars x 4
LGA 2011 Screw Pillars x 4
CP-7 x 1
Installation Guide x 1
