Intelligent LCD CP685AVRLCD, 685 VA/390 W, Simulated Sine Wave, Tower UPS
Quantity:
- SKU: 1941129
- Manufacturer: CYBERPOWER SYSTEMS
- MPN: CP685AVRLCD
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$115.95
Intelligent LCD CP685AVRLCD, 685 VA/390 W, Simulated Sine Wave, Tower UPS
The CyberPower Intelligent LCD CP685AVRLCD uninterruptible power supply (UPS) for mid to high-end computer systems, features dynamic line conditioning to guard against surges/spikes and offers battery backup in the event of brownouts or blackouts. Its patented GreenPower UPS? advanced circuitry reduces UPS energy costs by up to 75% compared to competitive models. The CP685AVRLCD unit has a capacity of 685VA/390Watts, eight (8) NEMA 5-15R receptacles, including four (4) fail-safe outlets for critical loads. The intelligent multi-function LCD panel displays real-time UPS vitals for ease of control. This unit offers connectivity via one (1) HID USB port, as well as protection for phone/network (RJ11/RJ45) and cable/coax (RG-6). It has one (1)
The CyberPower Intelligent LCD CP685AVRLCD uninterruptible power supply (UPS) for mid to high-end computer systems, features dynamic line conditioning to guard against surges/spikes and offers battery backup in the event of brownouts or blackouts. Its patented GreenPower UPS? advanced circuitry reduces UPS energy costs by up to 75% compared to competitive models. The CP685AVRLCD unit has a capacity of 685VA/390Watts, eight (8) NEMA 5-15R receptacles, including four (4) fail-safe outlets for critical loads. The intelligent multi-function LCD panel displays real-time UPS vitals for ease of control. This unit offers connectivity via one (1) HID USB port, as well as protection for phone/network (RJ11/RJ45) and cable/coax (RG-6). It has one (1)
- Capacity: 685 VA / 390 W
- Topology: Line Interactive
- Waveform: Simulated Sine Wave
- Output: 120 VAC ± 5%
- Plug type & cord: NEMA 5-15P, 6 ft. cord
- Outlet types: 8 × NEMA 5-15R
- Communication: USB
- Management software: PowerPanel® Personal
- ENERGY STAR® qualified: Yes
- Warranty: 3 year
| General | |
| UPS Topology | Line Interactive |
| ENERGY STAR® Qualified | Yes |
| Energy Saving | GreenPower UPS™ Bypass |
| Input | |
| Frequency Range | 57 – 63 Hz |
| Plug Type | NEMA 5-15P |
| Plug Style | Right Angle, 45° Offset Right |
| Cord Length | 6 ft |
| Output | |
| VA | 685 VA |
| Watts | 390 W |
| Automatic Voltage Regulation | Yes |
| On Battery Voltage | 120 VAC ± 5% |
| On Battery Frequency | 60 Hz ± 1% |
| On Battery Waveform | Simulated Sine Wave |
| Outlet Type | NEMA 5-15R |
| Outlets – Total | 8 |
| Outlets – Battery & Surge Protected | 4 |
| Outlets – Surge-Only Protected | 4 |
| Outlets – Widely Spaced | 4 |
| Overload Protection |
Internal Circuitry Limiting
Circuit Breaker |
| Transfer Time | 4 ms |
| Battery | |
| Runtime at Half Load (min) | 11 |
| Runtime at Full Load (min) | 2 |
| Battery Type | Sealed Lead-Acid |
| Battery Size | 12V/7Ah |
| Battery Quantity | 1 |
| Hot-Swappable | Yes |
| User Replaceable | Yes |
| Replacement Battery Cartridge | RB1270B |
| Replacement Battery Cartridge Quantity | 1 |
| Typical Recharge Time | 8 hours |
| Surge Protection & Filtering | |
| Surge Suppression | 1,030 J |
| EMI/RFI Filtration | Yes |
| Management & Communications | |
| Multifunction LCD Panel | Displays: Current/Load Level, Runtime, Battery Level, Input Voltage, Output Voltage, Battery In Use, Overload, Silent Mode, Normal Mode |
| HID Compliant USB Port | Yes |
| LED Indicators | Power On, Wiring Fault |
| Audible Alarms | On Battery, Low Battery, Overload, Fault |
| Software | PowerPanel® Personal |
| Physical | |
| Form Factor | Compact |
| Color | Black |
| Keyhole Mounting Slots | Yes |
| Dimensions – WxHxD (in) | 11 x 6.8 x 3.5 |
| Weight (lbs) | 11.62 |
| Environmental | |
| Operating Temperature | 32 °F to 95 °F / 0 °C to 35 °C |
| Operating Relative Humidity | 0 – 90% (non-condensing) |
| Storage Temperature | 5 °F to 113 °F / -15 °C to 45 °C |
| Maximum Operating Elevation | 10,000 ft (3,000 m) |
| Maximum Storage Elevation | 50,000 ft (15,000 m) |
| Certifications | |
| Safety | UL1778, cUL 107.3, FCC DOC Class B |
| Environmental | RoHS Compliant |
| Warranty | |
| Product Warranty | 3 Years Limited |
| Connected Equipment Guarantee | Lifetime |
