| Product Overview |
| Power Rating |
1500VA / 1350W |
| Input Voltage |
Typical: 120V / Range: 60-150V |
| Output Voltage |
110/115/120/125VAC; (user-configurable); ±3% |
| Efficiency |
Up to 98% Active ECO Mode; up to 95% on-line mode |
| Wiring |
Input: NEMA 5-15P A; Output: 5-15R × 6 |
| Interfaces/Ports |
| Interface Options |
Optional communications card (Vertiv™ RDU101), USB, RS485, RS232, terminal block, external battery connector |
| Protocols |
SNMP and web management enabled with optional Vertiv RDU101 communications card; serial connection for out-of-band management |
| Control Panel |
Colored graphic LCD with gravity sensing orientation, provides insight to UPS status for easy installation, configuration and operation |
| Operational Conditions |
| Operating Temperature |
+32 to +104 °F (0 to 40 °C) |
| Miscellaneous |
| General |
Output Receptacles: 5-15R × 6; 4x individually programmable receptacles and 2x non-programmable receptacles |
| Listings |
ENERGY STAR® 2.0 certified, WEEE, RoHS2, REACH, UL 1778 4th edition and CSA 22.2 No. 107.1 |
| Topology |
On-line double conversion UPS; compact and flexible rack/tower form factor |
