METIS EVO ALS, No PSU, Mini-ITX, Blue, Mini Cube Case
- SKU: 14023843
- Manufacturer: RAIJINTEK
- MPN: 0R20B00169
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
METIS EVO
Design Art in its best by RAIJINTEK Blue (0R20B00169) – New series of SFF chassis. The METIS EVO case is designed to fulfill a smallest case built with Ultra high air flow to solve all thermal issue of SFF chassis nowadays, can even install 200mm fan at front & 120mm/140mm/200mm AIO and DIY water-cooling. METIS EVO case supports up to Mini-ITX motherboard, able to install an ultra-high air flow 200mm at front (option), also can install 120/140/200mm radiator at front too (Optional), a 120 + 92mm fan optional at bottom, 2*9225 at rear (Option). METIS EVO Superior features includes elegant Sand Blasting on Aluminum, 3.5”*2 HDD + 2.5”*2 HDD/SSD, VGA card length of 280mm (without radiator280mm ; up to 220mm with 30mm thickness radiator installed) can fit most powerful GTX 1080Ti Mini or up to RTX 2080Ti twin fan video card, tool-free for easy installation, ATX /SFX PSU compatibility (SFX switch bracket included) . Looking for a best of best SFF case with no thermal issue, METIS EVO is the one.
- Aluminum Sand Blasting appearance design
- Entire Coating black internally design
- Compatible with ATX POWER SUPPLY
- Compatible with 280 mm VGA card
- Supports to max. 135mm height CPU cooler
- Type C×1 + USB3.0×1
- All Magnetic dust filters
- Supports to install 2×2.5"HDD + 2×3.5"HDD
- Option to install 200mm×1 or 1×12025 or 1×14025 fan at front; 1×120 fan at bottom (option), 2×9025 at rear (optional)
- Option to install 200mm or 120mm or 140mm radiator at front
- Mesh front panel for Ultra high air flow design
| Product Name | METIS EVO ALS |
| Product Number | 0R20B00169 |
| Dimension [W×D×H] | 293×290×263 mm |
| Weight | 3.6 kg [N.W.] 4.6 kg [G.W.] |
| Material | Aluminum 2.0mm; SPCC 0.8mm |
| Color | Blue |
| M/B Support | MINI-ITX |
| Drive Bay | 3.5"HDD × 2 + 2.5"SSD × 2 |
| Expansion Slot | PCI Slots ×2 |
| I/O Panel | USB3.0×1, C-TYPE×1 |
| Power Supply | PS/2 [Internal Bottom-mount] / SFX |
| Fan Q’ty |
Front: 200mm×1 [option] or 120/140mm [option] Bottom: 120mm×1 & 92mm×1 [option] Rear: 92mm×2 [option] |
| Radiator Q’ty | 1×200mm [option] |
| Pump/water tank | 1 [option] |
| CPU Cooler Height | 135mm [Max.] |
| Graphic Card Length | 280mm [without 200mm radiator]; 220mm [with 200mm radiator] |
| Side Panel Style | Aluminum |
