MPD 539004-000, Zero U PDU
- SKU: 13965060
- Manufacturer: Marway
- MPN: MPD 539004-000
- Availability: CONTACT US
Price
$1,217.84
| Power Outlets | |
| Front Panel | (36) 5-20R, 120V |
| Rear Panel | None |
| Other Panels | None |
| Power Input | |
| Voltage | 120/208 Vac |
| Phase | 3-Phase Wye |
| Frequency | 50/60 Hz |
| Max Current | 30 Amps |
| Max Load | 2.88 KVA, 8.63 KVA |
| Connection | L21-30P, 15 ft cord, 5-wire 10 ga, SOOW jacket (End panel) |
| Voltage Monitor | None |
| Current Monitor | None |
| Power Protection | |
| Spike/Surge | None |
| EMI Filter | None |
| Over Current | (6) 20A Circuit Breaker |
| Remote, Interlocks, and Environment Sensors | |
| Local EPO | None |
| Remote EPO Type | None () |
| Interlocks | 0 |
| Temperature | 0 |
| Humidity | 0 |
| Communications and Interfaces | |
| Display | None |
| Serial | None |
| Ethernet | None |
| Protocols | None |
| Physical | |
| Layout | Zero U |
| Dimensions | 66" H x 2.25" W x 3.5" D |
| Weight | 25 lbs Estimated |
| Materials | Chassis: Steel |
| Finishes |
Chassis: Zinc plated Black FrontPanel: Zinc plated Black |
| Operating Conditions | |
| Temperature | 32° to 122° Fahrenheit |
| Humidity | 5% to 85% Relative Humidity |
| Elevation | 6,562 feet |
| Conformance | |
|
Warranty
|
See warranty page for details |
| Conformances | UL |
