MPG A1000G PCIE5, 80 PLUS Gold 1000W, Fully Modular, ATX Power Supply
Quantity:
- SKU: 15141951
- Manufacturer: MSI
- MPN: MPGA1000GPCIE5
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$146.26
MPG A1000G PCIE5, 80 PLUS Gold 1000W, Fully Modular, ATX Power Supply
The MPG power supply showcases unique styles and color schemes with laser-like lines to create a masterful art piece with individuality, fully expressing the charm of MPG.
It has an output port that is compliant with PCIe 5.0 and Intel PSDG (Power Supply Design Guide) ATX 3.0, also the power supply can hold up to 2x total power excursion and 3x GPU power excursion.
- Supports Nvidia® GeForce RTXTM 40 Series graphics cards
- Full modular design
- Flat cables
- 80 Plus Gold certified for high efficiency
- 100% all Japanese 105oC capacitor
- Active PFC design
- Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP
- LLC Half Bridge Topology with DC-DC module design
| EFFICIENCY RATING | 80 PLUS Gold (up to 90%) | ||||
| MODULAR | Yes (fully modular) | ||||
| FAN SIZE | 135 mm | ||||
| FAN BEARING | Fluid Dynamic Bearing | ||||
| DIMENSIONS (DXWXH) | 150 x 150 x 86 mm | ||||
| PFC TYPE | Active PFC | ||||
| INPUT VOLTAGE RANGE | 100~240 VAC | ||||
| POWER WATT | 1000W | ||||
| POWER EXCURSION | 2000W (*up to 200% of the PSU's rated power for 100μs) | ||||
| INPUT FREQUENCY RANGE | 50~60 Hz | ||||
| PROTECTION | OCP / OVP / OPP / OTP / SCP / UVP | ||||
| ATX (24 PIN) | 1 | ||||
| EPS (4+4 PIN) | 2 | ||||
| PCI-E 5.0 (16 PIN) | 1 (600W) | ||||
| PCI-E (6+2 PIN) | 6 | ||||
| SATA (15 PIN) | 12 | ||||
| MOLEX (4 PIN) | 4 | ||||
| FDD (4 PIN) | 1 | ||||
| SPECIFICATION / FICHE TECHNIQUE | |||||
| AC Input | 100-240V~, 13.0A, 50~60Hz | ||||
| DC Output | +5V | +3.3V | +12V | -12V | +5Vsb |
| 22.0A | 22.0A | 83.5A | 0.3A | 3.0A | |
| Total Power | 120W | 1000W | 3.6W | 15W | |
| 1000W | |||||
