MPG A750G PCIE5, 80 PLUS Gold 750W, Fully Modular, ATX Power Supply
Quantity:
- SKU: 15783471
- Manufacturer: MSI
- MPN: MPGA750GPCIE5
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$125.10
MPG A750G PCIE5
- Supports Nvidia® GeForce RTX® 40 Series graphics cards
- Full modular design
- Flat cables
- 80 Plus Gold certified for high efficiency
- 100% all Japanese 105oC capacitor
- Active PFC design
- Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP
- LLC Half Bridge Topology with DC-DC module design
| MODULAR | Yes (full modular) |
| PRODUCT NAME | MPG A750G PCIE5 |
| FAN BEARING | Fluid Dynamic Bearing |
| PSU FORM FACTOR | ATX |
| POWER WATT | 750W |
| INPUT VOLTAGE RANGE | 100~240 VAC |
| POWER EXCURSION | 1500W (*up to 200% of the PSU's rated power for 100μs) |
| INPUT FREQUENCY | 50~60 Hz |
| ATX (24 PIN) | 1 |
| EFFICIENCY | 80 PLUS Gold (up to 90%) |
| EPS (4+4 PIN) | 2 |
| FAN SIZE | 135 mm |
| PCI-E 5.0 (16 PIN) | 1 (450W) |
| DIMENSION | 150 x 150 x 86 mm |
| PCI-E (6+2 PIN) | 6 |
| PFC TYPE | Active PFC |
| SATA (15 PIN) | 8 |
| PROTECTION | OCP / OVP / OPP / OTP / SCP / UVP |
| MOLEX (4 PIN) | 4 |
| FDD (4 PIN) | 1 |
| UPC | 0824142293041 |
