MWE GOLD 1250 - V2 ATX 3.0, 80 PLUS Gold 1250W, Fully Modular, ATX Power Supply
Quantity:
- SKU: 15836737
- Manufacturer: COOLER MASTER
- MPN: MPE-C501-AFCAG-3US
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$147.26
MWE GOLD 1250 - V2 ATX 3.0, 80 PLUS Gold 1250W, Fully Modular, ATX Power Supply
100% ATX 3.0 COMPATIBLE
Cooler Master took the initiative and continuously developing our first ATX3.0 Power Supply lineup. Compliant with ATX3.0 standard and 12VHPWR connectors, the MWE Gold 1250 - V2 ATX3.0 can fully support the peak power drawn by the 40 series RTX graphic cards and whole system.
- 80 PLUS Gold Efficiency
- 100% Japanese Capacitor
- 140mm Silent Fan
- High Temperature Resilience
- Fully Modular Cabling
- 10 Year Warranty
| Model | MPE-C501-AFCAG-3 |
| ATX Version | ATX Rev. 3.0 |
| PFC | Active PFC |
| Input Voltage | 100-240V |
| Input Current | 15-7A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 180 x 150 x 86 mm |
| Fan Size | 140mm |
| Fan Bearing | FDB |
| Efficiency | ≥90% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Gold |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-50°C |
| Power Good Signal | 100 - 150 ms |
| Hold Up Time | ≥16ms at 100% Load |
| MTBF | >100,000 Hours |
| Protections | OVP, OPP, SCP, OCP, UVP, OTP, Inrush Protection |
| Regulatory | TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | 1 |
| EPS 8 Pin Connector | 1 |
| SATA Connectors | 12 |
| Peripheral 4 Pin Connectors | 4 |
| PCI-e 6+2 Pin Connectors | 3 |
| 12VHPWR Connector | 1 |
| Series | MWE Gold Series |
| 80 Plus | Gold |
| Modular | Full Modular |
| Wattage | Above 750W |
