Meshify 3 XL Solid, No PSU, E-ATX, Black, Full Tower Case
- SKU: 19008413
- Manufacturer: Fractal Design
- MPN: FD-C-MES3X-01
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Price
$223.00
| Specifications | |
| 3.5"/2.5" drive mounts | 2/4 |
| Dedicated 2.5" drive mounts | 1 |
| 5.25” drive mounts | - |
| Expansion slots | 7 |
| Adjust Pro Hub | Included in Ambience Pro RGB version |
| Ambience Case Lighting | Ambience Pro RGB version |
| Front interface | 1 x USB Type-C 20 Gbps, 2 x USB Type-A 5 Gbps, 1x Audio Combo Jack, Power button |
| Total fan mounts | 10 (120 or 140 mm) |
| Front fan | 3x 120/140 mm, 2x 180 mm (3 x 140 mm Momentum Included) |
| Top fan | 3x 120/140 mm |
| Rear fan | 1x 120/140 mm |
| Bottom fan | - |
| Side fan | 3x 140 mm (no 120 support without radiator) |
| Dust filters | PSU (Bottom) |
| Cable routing space | 37,5 mm |
| Cable cover | Yes |
| Cable organizers | 3 Hook-and-loop straps + 3 Cable Aligners |
| Tool-less push-to-lock | Both Side Panels, Bottom Filter, Front Panel, Top Panel |
| Captive thumbscrews | Top Radiator Bracket, Air Guide, PSU Bracket |
| Left side panel | Industrial steel (Solid), Tempered Glass (TG/RGB/Ambience Pro RGB) |
| Right side panel | Industrial steel |
| Compatibility | |
| Power supply type | ATX |
| Motherboard compatibility | E-ATX (330 mm) / ATX / mATX / ITX / EE-ATX / SSI-EEB / SSI-CEB |
| PSU max length | 230 mm |
| GPU max length | 512mm |
| GPU max height | 189 mm (7 slot) including cables |
| CPU cooler max height | 182 mm |
| Front radiator | 280/360 mm |
| Top radiator | 360/420 (up to 475) mm |
| Rear radiator | Up to 120/140 mm |
| Bottom radiator | - |
| Dimensions | |
| Case dimensions (LxWxH) | 575 x 245 x 515 mm |
| Case dimensions w/o feet/protrusions/screws | 565 x 245x 515 |
| Package dimensions | 596 x 350 x 550 mm |
| Net weight | 10.5 kg (Solid) 10.9 kg (TG and RGB) 11.4 kg (Ambience Pro RGB) |
| Gross weight | 12.4 kg (Solid) 13 kg (TG and RGB) 13.3 kg (Ambience Pro RGB) |
| Other | |
| Package contents | Case, Accessory Box, Manual, Red Note |
| Accessory Box content (Solid/TG/RGB) | PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8 |
| Accessory Box content (Ambience Pro RGB) | PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8, 500 mm Fractal Connect Cable x1, Legacy Splitter Cable |
| EAN |
Black Solid: 7340172707219 Black TG Light Tint: 7340172707226 Ambience Pro RGB Black TG Light Tint: 7340172707233 Black RGB TG Light Tint: 7340172709527 Ambience Pro RGB White TG Clear Tint: 7340172707240 White RGB TG Clear Tint: 7340172709534 |
| UPC |
Black Solid: 843276107215 Black TG Light Tint: 843276107222 Ambience Pro RGB Black TG Light Tint: 843276107239 Black RGB TG Light Tint: 843276109523 Ambience Pro RGB White TG Clear Tint: 843276107246 White RGB TG Clear Tint: 843276109530 |
| Product Code |
Black Solid: FD-C-MES3X-01 Black TG Light Tint: FD-C-MES3X-02 Ambience Pro RGB Black TG Light Tint: FD-C-MES3X-03 Black RGB TG Light Tint: FD-C-MES3X-04 Ambience Pro RGB White TG Clear Tint: FD-C-MES3X-05 White RGB TG Clear Tint: FD-C-MES3X-06 |
| Warranty | 2 Years |
