Meshlicious Tempered Glass, PCIe 3.0, No PSU, Mini-ITX, Black, (SFF) Small Case
Quantity:
- SKU: 14487475
- Manufacturer: SSUPD
- MPN: Meshlicious TG Black
- Availability: CONTACT US
Starting At
$124.25
Meshlicious Tempered Glass, PCIe 3.0, No PSU, Mini-ITX, Black, (SFF) Small Case
Meshlicious is a combination of MESH and Delicious. There’s so much mesh that your mouth will water. Breathable, mesh panels lets you savor the airflow and minty temps.
- Fine mesh panels and well ventilated
- 14.67 liters in size
- Support for regular size hardware
- High quality powder coated SGCC steel
- Tool-less external panels and easy to assemble
| Model | |
| Brand | SSUPD |
| Series | Meshlicious |
| Model | Meshlicious TG Black |
| Details | |
| Type | Mini-ITX |
| Color | Black |
| Case Material | Steel, Tempered Glass, Fine Mesh panel |
| Power Supply | ATX (Up to 170mm without radiator); ATX (Up to 150mm with radiator), SFX, SFX-L |
| Power Supply Mounted | Bottom |
| Motherboard Compatibility | Mini-ITX, Mini-DTX (Require extra 20cm PCIe riser card) |
| Side Panel Window | Yes |
| Dust Filters | No |
| Expansion | |
| Internal 3.5" Drive Bays | With SFF GPU: 2 x 3.5" drives max |
| Internal 2.5" Drive Bays | With Full Length GPU & SFX PSU: 3 x 2.5"drives max; With Full Length GPU & ATX PSU: 2 x 2.5"drives max; With SFF GPU: 7 x 2.5" drives max |
| Expansion Slots | Full Length GPU: Up to 4 slots; SFF GPU: Up to 3 slots |
| Front Panel Ports | |
| Front Ports | 1x USB Type-C 3.1 Gen2, 1x USB 3.0, Power LED |
| Cooling System | |
| Radiator Installed | No |
| Radiator Options | 120/140/240/280 mm (Up to 143 mm width, 62 mm thickness with fans depending on GPU position and type) |
| 120mm Fans | Front: 2 x 120mm fan |
| 140mm Fans | Front: 2 x 140mm fan |
| Dimensions & Weight | |
| Max GPU Length | Full Length GPU at 3 slots mode: Up to 332mm length and 155mm tall; Full Length GPU at 4 slots mode: Up to 336mm length and 155 mm tall; Small Form Factor GPU: Up to 211mm length (without radiator) |
| Max CPU Cooler Height | 73mm height in 3 slots mode; 53mm height in 4 slots mode |
| Max PSU Length | 170mm (without radiator); Recommend PSU below 150mm length |
| Dimensions (H x W x D) | 14.17" x 6.55" x 9.65" |
| Weight | 8.05 lbs. |
| Additional Info | |
| Features | Aesthetic look with excellent ventilation of fine mesh panels |
| Package Content | Meshlicious TG Version Case, Install Kit, Manual, PCIe 3.0 riser card, Right Angle HDMI 2.0 Cable (6.6ft) |
