Milo 10 SST-ML10B, No PSU, Mini-ITX, Black, Slim Case

SKU: 13563401

Manufacturer: SILVERSTONE

MPN: SST-ML10B

Availability: Unknown


Price: $63.24
or as low as $2/month
Quantity:

SilverStone Milo 10 SST-ML10B. Modular design. Interchangeable solid bezel and slim ODD bezel included for easily changing case size which allows different drive configurations to accommodate various storage components based on the height of your CPU coolers.

  • Super small at only 2.8 liters or 3.7 liters (includes interchangeable top cover for altering case size)
  • Modular design creates different configurations to accommodate various components (9.5mm slim ODD, 3.5" HDD, 2.5" SSD, 120/140mm fan)
  • Includes VESA mounting plate for integration with monitors
  • Adjustable / removable device bracket
  • USB 3.0 x 2
Model No. SST-ML10B (black)
Material Plastic bezel, steel body
Motherboard Mini-ITX
Drive bay External Standard top cover: N/A
Elevated top cover: 9.5mm slim optical bay
Internal Standard top cover: 2.5" x 2
Elevated top cover: 2.5" x 2 or 3.5" x 1*
Cooling system Front --
Rear --
Side Right side: 5010mm x 3
Left side: Ventilation
Top Standard top cover: Ventilation
Elevated top cover:120mm/140mm x 1 ( built-in M.2 , w/o SSD)
Bottom --
Internal --
Front I/O port USB 3.0 x 2
Power supply DC board + external AC adapter (sold separately)
Limitation of CPU cooler Standard top cover:
31mm (install 7mm height SSD inside)

Elevated top cover:
(1) 29mm (install HDD inside)
(2) 31mm (install 7mm height SSD and ODD inside w/o HDD bracket standoff)
(3) 36mm (Install M.2 + 25mm thickness 120mm / 140mm fan, w/o HDD/SSD bracket)
(4) 47mm (install 7mm height SSD inside w/ HDD bracket standoff)
(5) 63mm (install M.2, and w/o SSD / HDD / top fan)
Net weight 1.4 Kg
Dimension Standard top cover: 196mm (W) x 63mm (H) x 227mm (D), 2.8 liters
Elevated top cover: 196mm (W) x 84mm (H) x 227mm (D), 3.7 liters
0" (W) x 2.48" (H) x 8.94" (D), . liters
Elevated top cover: 0" (W) x 3.31" (H) x 8.94" (D), 3.7 liters
Remark
* When 3.5" drive is installed, slim ODD will not be able to be installed at the same time
