NEO QUBE 2, Tempered Glass, No PSU, E-ATX, White, Mid Tower Case

Quantity:
  • SKU: 15382571
  • Manufacturer: PHANTEKS
  • MPN: MG-NE620Q_DWT02
  • Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$142.58
Quantity:
NEO QUBE 2, Tempered Glass, No PSU, E-ATX, White, Mid Tower Case

The NEO Qube 2 is a true showcase mid-tower chassis without compromise. Its dual chamber design makes installation and cable management a breeze while all system components are highlighted through the double tempered glass panels. Available in Black, White, and infinity mirror editions.

OPTIONS
MODEL NO. MG-NE620Q_DWT02
UPC 886523900689
VARIANTS White
CONTENTS
DIMENSIONS 270 x 450 x 460 mm | 10.7 x 17.9 x 18.3 in
FORM FACTOR Mid Tower
MATERIALS Steel Chassis, Tempered Glass Windows
MB SUPPORT E-ATX, ATX, micro-ATX, mini-ITX
FRONT I/O USB 3.1 gen 2 type-C, 2x USB 3.0, Microphone/Headphone,
D-RGB Mode Button, D-RGB Color Button, Power Button, Reset Button
SIDE WINDOW Yes, Tempered Glass front and left-side window
NET WEIGHT 8.80 kg | 19.4 lbs
GROSS WEIGHT 10.50 kg | 23.15 lbs
PACKAGE DIMENSIONS 510 x 358 x 554mm | 20.1 x 14.1 x 21.8 in
FAN SUPPORT 120 MM 140 MM
SIDE 3x -
TOP 3x 2x
BOTTOM 3x 2x
RADIATOR SUPPORT
SIDE Up to 360 -
TOP Up to 360 Up to 280
BOTTOM Up to 360 -
PCI SLOTS & DRIVE BAYS
PCI SLOTS 8 slots
Vertical GPU Yes, with optional Vertical GPU Bracket
INTERNTAL 3.5" 2 (2x included)
INTERNTAL 2.5" 5 Included (3x if 3.5" bays are used)
CLEARANCE
GPU LENGTH 410 mm | 16.1 in
MOTHERBOARD WIDTH 280 mm | 11.0 in
CPU COOLER HEIGHT 148 mm | 5.9 in
PSU (INCLUDING CABLE) 275 mm | 10.9 in (155 mm if lower SSD’s installed)
SIDE RADIATOR 128 x 400 mm
SIDE RADIATOR THICKNESS 50mm (behind MB tray)
TOP RADIATOR 140 x 430 x 75 mm
BOTTOM RADIATOR 130 x 410 mm
SCOPE OF DELIVERY
NEO QUBE 2 CHASSIS
ACCESSORY BAG/BOX
ZIP TIES 6x
MB/SSD Screw 33x
PSU Screw 4x
HDD Cage Screw 8x
MB stand-off 5x
