| Size |
60x60x25 mm |
| Mounting hole spacing |
50x50 mm |
| Connector & pin-configuration |
4-pin PWM |
| Cable length |
20cm + 30cm NA-EC1 extension cable |
| Bearing |
SSO2 |
| Blade geometry |
A-Series with Flow Acceleration Channels |
| Frame technology |
AAO (Advanced Acoustic Optimisation) |
| Rotational speed (+/- 10%) |
3000 RPM |
| Rotational speed with L.N.A. (+/- 10%) |
2300 RPM |
| Min. rotational speed @ 20% PWM (+/-20%) |
550 RPM |
| Airflow |
29,2 m³/h |
| Airflow with L.N.A. |
22,6 m³/h |
| Acoustical noise |
19,3 dB(A) |
| Acoustical noise with L.N.A. |
13,7 dB(A) |
| Static pressure |
2,18 mm H2O |
| Static pressure with L.N.A. |
1,29 mm H2O |
| Input power (max.) |
0,96 W |
| Max. input current |
0,08 A |
| Operating voltage |
12 V |
| MTTF |
> 150.000 h |
| Scope of delivery |
- Low-Noise Adaptor (L.N.A.)
- 4-Pin Y-Cable
- 30cm Extension Cable
- 4 Vibration-Compensators
- 4 Fan Screws
|
| Warranty |
6 years |
