Specifically designed for pressure demanding applications such as CPU or radiator cooling, the classic NF-P12 is a long-standing favourite among enthusiast users around the world and helped to found Noctua’s reputation as a top-tier manufacturer of premium quality quiet cooling components. The new redux edition reissues this award-winning model in a streamlined, accessibly priced package that has been reduced to the essential core: the NF-P12 premium fan. Its industry grade SSO bearing, over 150.000 hours MTTF rating and full 6 years manufacturer’s warranty make the NF-P12 redux a proven premium choice that provides trusted Noctua quality at an attractive price point. The extra slow 900rpm 3-pin version is ideal for ultra-low-noise applications and highly noise sensitive users who demand near-silent operation.
- Ultra low noise fan, 120x120x25 mm, 12V, 3-pin Molex, 900 RPM, 12.6 dB(A), >150,000 h MTTF
- Renowned NF-P12 high-end 120x25mm 12V fan, more than 100 awards and recommendations from international computer hardware websites and magazines, hundreds of thousands of satisfied users
- Pressure-optimised blade design with outstanding quietness of operation: high static pressure and strong CFM for air-based CPU coolers, water cooling radiators or low-noise chassis ventilation
- Low-speed ultra-quiet 900rpm 3-pin version for demanding silent enthusiasts, virtually inaudible with optional NA-SRC10 Low-Noise Adaptors or at reduced voltage
- Streamlined redux edition: proven Noctua quality at an attractive price point, wide range of optional accessories (anti-vibration mounts, S-ATA adaptors, y-splitters, extension cables, etc.)
FAN Specification | |
Size | 120x120x25 mm |
Mounting hole spacing | 105x105 mm |
Connector & pin-configuration | 3-pin |
Cable length | 40cm |
Bearing | SSO-Bearing |
Blade geometry | Pressure-optimized Nine Blade Design with Vortex-Control Notches |
Rotational speed (+/- 10%) | 900 RPM |
Airflow | 63,4 m³/h |
Acoustical noise | 12,6 dB(A) |
Static pressure | 1,21 mm H2O |
Max. input power | 0,3 W |
Max. input current | 0,025 A |
Operating voltage | 12 V |
MTTF | > 150.000 h |
Scope of delivery |
|
Warranty | 6 years |
