Essentials | |
---|---|
Product Collection | Intel® NUC Compute Elements |
Code Name | Products formerly Ghost Canyon |
Status | Launched |
Launch Date | Q1'20 |
Supported Operating Systems | Windows 10, 64-bit*, Linux* |
Board Number | NUC9i7QNB |
Board Form Factor | PCIe |
Internal Drive Form Factor | M.2 SSD |
# of Internal Drives Supported | 2 |
Board Chipset | Mobile Intel® CM246 Chipset |
Processor Included | Intel® Core™ i7-9750H Processor (12M Cache, up to 4.50 GHz) |
Intel® vPro™ Platform Eligibility | No |
# of Cores | 6 |
# of Threads | 12 |
Processor Base Frequency | 2.60 GHz |
Max Turbo Frequency | 4.50 GHz |
Warranty Period | 3 yrs |
Supplemental Information | |
Embedded Options Available | No |
Memory & Storage | |
Max Memory Size (dependent on memory type) | 64 GB |
Memory Types | DDR4-2666 |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 42.6 GB/s |
Max # of DIMMs | 2 |
ECC Memory Supported | No |
Processor Graphics | |
Processor Graphics | Intel® UHD Graphics 630 |
Integrated Graphics | Yes |
Graphics Output | 2x Thunderbolt 3, HDMI 2.0a |
# of Displays Supported | 3 |
Expansion Options | |
PCI Express Revision | Gen3 |
PCI Express Configurations | 2x M.2 PCIe X4 slots (PCH) |
M.2 Card Slot (storage) | 2x via PCH (SATA or NVMe) |
I/O Specifications | |
# of USB Ports | 10 |
USB Configuration | 4x rear USB 3.1g2, 2x Thunderbolt 3 (USB 3.1g2), 2x USB3.1g2 "Type-C" ports via internal header, 2x USB 2.0 via internal headers |
USB Revision | 3.1 Gen2, 2.0 |
USB 2.0 Configuration (External + Internal) | 2x int. |
Total # of SATA Ports | 3 |
Max # of SATA 6.0 Gb/s Ports | 3 |
RAID Configuration | 2x M.2 SATA/PCIe SSD, SATA header (RAID-0 RAID-1) |
Audio (back channel + front channel) | 7.1 digital; L+R+mic (F); L+R+TOSLINK (R) |
Integrated LAN | Intel® Ethernet Connection i219-LM and i210-AT |
Integrated Wireless | Intel® Wi-Fi 6 AX200 |
Integrated Bluetooth | Yes |
S/PDIF Out Connector | TOSLINK |
Additional Headers | CEC, 2x USB2.0, FRONT_PANEL |
# of Thunderbolt™ 3 Ports | 2 |
Package Specifications | |
Chassis Dimensions | 203 x 131 x 38mm |
Advanced Technologies | |
Intel® Optane™ Memory Supported | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® vPro™ Platform Eligibility | No |
TPM | Yes |
Intel® Rapid Storage Technology | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Platform Trust Technology (Intel® PTT) | Yes |
Security & Reliability | |
Intel® AES New Instructions | Yes |
