| Case Specifications |
| Dimension |
575 x 280 x 615 mm / 22.63 x 11.02 x 24.21 in (DxWxH) |
| Form Factor |
Full Tower |
| Material(s) |
Steel Chassis, Tempered Glass |
| Motherboard Support |
ATX, micro-ATX, mini-ITX, SSI-CEB, E-ATX (up to 280mm wide) Reverse motherboard connectors, BTF, Project Zero |
| Front I/O |
2x USB 3.0, USB-C 3.2 Gen2, Microphone/Headphone Combo, Power Button, D-RGB Mode, D-RGB Color, D-RGB Speed, D-RGB Channel |
| Connectors |
Power Switch, 2x D-RGB Channel A, 2x D-RGB Channel B, HD-audio, USB 3.0, 2x SATA Power, USB 3.2 GEN 2 Type-E, Power LED |
| Window |
Yes, Front and Side Tempered Glass |
| Expansion & Drive Bays |
| Expansion slots |
8 |
| Vertical GPU support |
Yes, with optional bracket PH-VGPUKT4.0_03R/PH-PGPUKT_01 |
| Internal 3.5” |
Max 3* (3x included) (*Max 24mm HDD height when SSDs installed) |
| Internal 2.5" |
Max 6 (6x included) (*2x if 3x HDD positions are used) |
| D-RGB Controller output |
7A per Channel, 4A per port (Total 14 Watt) |
| Cooling |
120mm fan |
140mm fan |
| Side |
4x |
3x |
| Top |
3x |
3x |
| Rear |
2x |
2x |
| Bottom |
3x |
3x |
| Liquid Cooling |
120mm radiator |
140mm radiator |
| Side |
Up to 480 |
Up to 420 |
| Top |
Up to 360 |
Up to 420 |
| Rear |
Up to 240 |
Up to 280 |
| Bottom |
Up to 360 |
Up to 420 |
| Clearance |
| Graphic card length |
490mm |
| Graphic card width |
205mm |
| CPU cooler height |
205mm |
| PSU length |
210mm |
| Side 360 Radiator |
525 x 154 mm |
| Top 360 Radiator |
515 x 154 mm |
| Rear 240 Radiator |
325 x 154 mm |
| Scope of delivery |
| Dual D-RGB Controller |
1x |
| Top LED Cover |
1x |
| Side LED Cover |
1x |
| Front IO-Module |
1x |
| Storage/Cable bracket |
1x |
| Storage Bracket |
1x |
| Accessory Box |
| GPU Support Bracket |
1x |
| Airflow Covers |
2x |
| Microfiber Cloth |
1x |
| Zip ties |
6x |
| Screw Assortment Box |
1x |
| MB/SSD Screw |
34x |
| Thumb Screw |
4x |
| HDD Screw |
9x |
| Standoff Removal Tool |
1x |
| MB stand-off |
1x |
| PSU Screw |
4x |
| Extra R-Side Panel Screw |
1x |
