P550B, 80 PLUS Bronze 550W, No Modular, ATX Power Supply

SKU: 13546180

Manufacturer: GIGABYTE

MPN: P550B

Availability: Available


Price: $78.69
or as low as $3/month
Quantity:

GIGABYTE P550B(GP-P550B). 120mm Silent Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.

  • 80 PLUS Bronze certified
  • 120mm Silent Hydraulic Bearing (HYB) Fan
  • Reliable flat cable
  • Single +12V rail
  • OVP/OPP/SCP/UVP/OCP/OTP protection
  • 3 years warranty (Adjusted according to different regions)
Model P550B
Type Intel Form Factor ATX 12V v2.31
PFC Active PFC(>0.9 typical)
Input Voltage 1‎00-240 Vac(full range)
Input Current 8‎-4 A
Input Frequency 6‎0-50 Hz
Output Capacity 5‎50W
Dimension 1‎50 x 140 x 86 mm
Fan Type 1‎20mm Hydraulic Bearing (HYB) Fan
80 PLUS Bronze
Efficiency 8‎5% at typical load
MTBF >100,000 hours
Protection OVP/OPP/SCP/UVP/OCP/OTP
Power Good Signal 1‎00-500ms
Hold Up Time >16ms
Cable Type Flat, All black
Connectors ATX/MB 20+4 Pin x 1 : 550mm*1
CPU/EPS 4+4 Pin x 1 : 600mm*1
PCI-e 6+2 Pin x 2 : 550mm+150mm*1
SATA x 6 : 500mm+120mm+120mm*2
4 Pin Peripheral x 3 + 4-Pin floppy x 1 : 500mm+120mm+120mm+120mm*1
