PEXSOUND7CH, 7.1 Channels, 24-bit / 192 kHz, 92 dB SNR, PCIe Sound Card

Quantity:
  • SKU: 9598815
  • Manufacturer: STARTECH.COM
  • MPN: PEXSOUND7CH
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$63.15
Quantity:
PEXSOUND7CH, 7.1 Channels, 24-bit / 192 kHz, 92 dB SNR, PCIe Sound Card

With this 7.1-channel PCIe sound card, you can create a high-quality home theatre sound system. It offers SPDIF input and output ports which deliver crystal-clear digital optical audio, for the ultimate listening experience.

Versatile performance

The versatile sound card can be used with a variety of audio devices. And with SPDIF digital optical or 3.5mm analog output, you don’t need to worry about the connection types on your devices. You can output digital audio to your optical receiver or DAC, or analog audio to your sound system.

With up to 24-bit and 192KHz playback and recording, this 7.1 surround sound adapter card delivers high-definition audio for superb sound quality.

Simple installation

Unlike typical sound cards, this card is designed to fit in low-profile computers, making it ideal for home theatre personal computers (HTPC). It spans the multiple ports across a main card plus an innovative separate header bracket. The card is configured with standard profile brackets and includes low-profile (half-height) brackets.

The 7.1 channel surround sound card is easy to install. It’s perfect for anyone looking for a simple solution to upgrade their listening experience, such as music enthusiasts or mixing professionals.

Multiple input options

For added scalability, you can quickly connect a microphone or other recording devices to your computer through two 3.5mm stereo or SPDIF digital audio input jacks.

The PEXSOUND7CH is backed by a StarTech.com 2-year warranty and free lifetime technical support.

  • Superb audio quality, with high-resolution 7.1 surround sound
  • Supports digital optical or analog audio devices through SPDIF or 3.5mm jacks
  • All ports fit in standard or small form-factor computers (low-profile brackets included), using the main card plus header bracket
  • Supports HD audio, with up to 24-bit and 192KHz playback and recording
  • Stereo microphone, line, and SPDIF inputs
  • ~92dB SNR (signal-to-noise ratio) at front output
  • Three internal auxiliary inputs (2x CD/DVD-IN and 1x Intel HD front panel audio)
  • Supports ASIO and WASAPI
Warranty Information
Warranty 2 Years
Connector(s)
Connector Type(s) 1 - PCI Express x1
Internal Ports 2 - MPC2 (4 pin, Audio)
2 - IDC (10 pin, Motherboard Header)
1 - IDC (9 pin, USB 2.0, Motherboard Header)
External Ports 2 - Toslink (SPDIF, Optical) 6 - 3.5 mm Mini-Jack (3 Position)
Environmental
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature -10C to 80°C (14°F to 176°F)
Humidity 10~90% RH
Hardware
Bus Type PCI Express
Card Type Standard Profile (LP bracket incl.)
Chipset ID C-Media - CM8828
Packaging Information
Package Height 1.3 in [32 mm]
Package Length 5.6 in [14.3 cm]
Shipping (Package) Weight 6.7 oz [190 g]
Package Width 6.9 in [17.5 cm]
Package Quantity 1
Performance
Audio Specifications
Full Duplex Support
Yes
Physical Characteristics
Weight of Product 3.5 oz [99 g]
Color Green
Material Steel
Product Length 4.3 in [10.9 cm]
Product Width 0.7 in [18 mm]
Product Height 4.7 in [12 cm]
Power
Input Voltage 12V DC
Software
OS Compatibility Windows® 11, 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64)
Special Notes / Requirements
System and Cable Requirements PCI Express enabled computer with an available PCI Express x1 slot or higher (x4, x8, x16)
Additional slot on your computer case if installing and using the header bracket
What's in the Box
Included in Package 1 - 7.1 Channel PCI Express Sound Card with Header Bracket & 10-pin Cable 2 - Low-Profile Brackets 1 - Instruction Manual
