PRIME PX-1600, 80 PLUS Platinum 1600W, Fully Modular, ATX Power Supply
Quantity:
- SKU: 16690128
- Manufacturer: SEASONIC
- MPN: SSR-1600PD2
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$531.00
PRIME PX-1600, 80 PLUS Platinum 1600W, Fully Modular, ATX Power Supply
PRIME PX ATX 3.0
The Seasonic PRIME PX ATX 3.0 Series is built on top of all the great features of PRIME PX platform with added ATX 3.0 and PCIe 5.0 compatibility. Currently the 1600 W is equipped with native 12VHPWR connectors and Digital Fan Control, and 105°C-rated Japanese electrolytic capacitors guarantee unwavering power delivery and long-term durability. All these qualities make this power supply perfect to welcome the newest high power graphic cards and processors on the market.
| Technical Specifications | ||||||
| 80PLUS® | Platinum | |||||
| Cybenetics Efficiency Level | Titanium | |||||
| Cybenetics Noise Level | A- | |||||
| Form Factor | ATX/EPS | |||||
| Dimensions | 210 × 150 × 86 mm | |||||
| Fan Information | Fan Size | 135 mm | ||||
| Fan Control | Digital Hybrid Fan Control | |||||
| Fan Bearing | Fluid Dynamic Bearing | |||||
| Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH | |||||
| Cable Information | Modularity | Fully Modular | ||||
| Cable type | Individual Black Cables with Braided Pattern | |||||
| Electrical Features | Operating Temperature | 0 - 50 °C | ||||
| MTBF @ 25 °C, excl. fan | 100,000 hours | |||||
| AC Input | Full Range | |||||
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |||||
| Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE | ||||
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |||||
| Warranty | 12 Years | |||||
| Power Output | ||||||
| AC Input | Voltage: 100 V - 240 V | |||||
| Current: 15 - 10 A | ||||||
| Frequency: 50 Hz–60 Hz | ||||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 25 A | 25 A | 133.3 A | 0.5 A | 3 A | |
| 125 W | 1600 W | 6 W | 15 W | |||
| Total continuous power | 1600 W 115—240Vac, 1300 W 100-240 Vac | |||||
