| Heatsink Specifications | |
| Dimension | L110 mm x W125 mm x H154 mm |
| Weight | 765g |
| Heat pipes | 6mm heatpipe x 7 units |
| Copper Base | C1100 Pure copper nickel plated |
| TL-C12B V2 FAN Spec | |
| Dimension | L120 mm x W120 mm x H25 mm |
| Weight | 135g |
| Rated Speed | 1500 RPM±10% (MAX) |
| Noise Level | 25.6 dBA |
| Air Flow | 66.17 CFM (MAX) |
| Air Pressure | 1.53 mm H2O (MAX) |
| Ampere | 0.20 A |
| Connector | 4 Pin (PWM Fan connector) |
| Bearing Type | S-FDB Bearing |
