ProSafe GSM7248-200NAS, 16 x RJ45, 10/100/1000Mbps, Ethernet Switch Retail

SKU: 1067

Manufacturer: NETGEAR

MPN: JGS516NA

Availability: Available


Price: $120.96
or as low as $4/month
Quantity:

The NETGEAR JGS500 Series of unmanaged 10/100/1000Mbps Gigabit switches provide expanded connectivity for small office networks at an economical price the value-conscious business owner can't ignore.

Prosafe 16-Port Gigabit Ethernet Switch
JGS516NA

Features:

  • 16 10/100/1000 ports
  • Powerful, non-blocking backplane
  • Affordable enough for desktop connections

Overview:

Take Gigabit to the Desktop

NETGEAR’s JGS500 Gigabit Switch Series gives your office network a megaboost of speed and capacity that is within your budget. With up to 48 Gbps of bandwidth, these 16- and 24-port switches can blast 2000 Mbps per port while their affordable prices enable you to put them everywhere. Use it to take Gigabit Ethernet directly to the desktop! Standards-based for easy integration of 10-, 100-, and 1000-Mbps devices, these unmanaged, rack-mountable switches feature 10/100/1000 automatic speed and full/half-duplex sensing plus Auto Uplink™ on every port. Users can take advantage of the their ability to deliver large amounts of multimedia, image, and video information in no time at all. Ideal for workgroups, labs, departments, or growing offices looking for oustanding performance at a low price.

High Capacity

1000-Mbps speeds and a switching capacity of up to 48 Gbps meet the performance needs for even the most bandwidth-hungry applications. The JGS500 series are perfect for graphics, multimedia, and other applications that have to move large files across the network quickly.

Affordable

Aggressive prices enable your workgroup, department or small network to ramp up to Gigabit speeds, even all the way to the desktop.

Flexible

Each port is equipped with automatic speed and duplex sensing, plus Auto Uplink to adjust for straight-through or crossover cables to make the right link. Standards-based design makes it easy to combine 10-, 100-, and 1000-Mbps devices on your network.

Convenient

Easy to set up and easy to use, these unmanaged switches have per port LED’s for effortless network monitoring. They are compact enough for the desktop but come with a rack-mount kit. They are also compatible with PC, Macintosh, Linux, and Unix operating systems.

NETGEAR Green

  • Up to 60% lower power consumption
  • Auto power-down mode saves energy 0;0;0;3; when port is unused
  • Less transmit power when the cable is under 10 m
  • Packaging manufactured with at least 80% recycled materials

Specification:

Network Ports

  • JGS516: 16 10/100/1000 Mbps twisted-pair RJ-45 ports
  • JGS524: 24 10/100/1000 Mbps twisted-pair RJ-45 ports

Performance

  • Switching bandwidth:
    -JGS516: 32 Gbps
    -JGS524: 48 Gbps
  • Forward rate (1000 Mbps port): 1,480,000 packets per sec
  • Forward rate (100 Mbps port): 148,000 packets per sec
  • Forward rate (10 Mbps port): 14,800 packets per sec
  • Jumbo frames latency (1000 to 1000 Mbps): 20 μs max
  • Packet buffer memory: 2 Mb
  • MAC address database: 8,000
  • Mean time between failures (MTBF):
    -JGS516: 309,000 hours (~ 35 years)
    -JGS524: 230,000 hours (~ 26 years
  • Acoustic noise: 40 dB

Power Consumption

  • 100-240V; 50-60 Hz; plug is localized to country of sale
  • JGS524: 16max
  • JGS516: 11max

Standards Compliance

  • IEEE 802.3i 10BASE-T Ethernet
  • IEEE 802.3u 100BASE-TX Fast Ethernet
  • IEEE 802.3ab 1000BASE-T Gigabit Ethernet
  • IEEE 802.3x flow control

Status LEDs

  • Unit: power
  • Per network port: Link, activity, speed

Physical Specifications

  • Dimensions (h x w x d): 43 x 330x 207 mm (1.7 x 13 x 8.2 in)
  • Weight: JGS516: 1.62 kg (3.57 lb); JGS524: 1.72 kg (3.79 lb)

Environmental Specifications

  • Operating temperature: 0° to 50° C (32° to 122° F)
  • Operating humidity: 90% maximum relative humidity, non-condensing
  • Storage temperature: -20° to 70° C (-4° to 158º F)
  • Storage humidity: 10 to 95% relative humidity

Electromagnetic Compliance

  • CE mark, commercial
  • FCC Part 15 Class A
  • VCCI Class A
  • EN 55022 (CISPR 22), Class A, EN 50082-1,
  • EN 55024
  • C-Tick

Safety Agency Approvals

  • UL listed (UL 1950)/cUL
  • IEC 950/EN 60950 System Requirements
  • UTP Category 5 cables or better
  • Network card for each PC or server Warranty
  • NETGEAR Lifetime Warranty†

ProSupport Service Packs Available

OnCall 24x7, Category 1

  • PMB0331-100 (US)
  • PMB0331 (non-US)

XPressHW, Category 1

  • PRR0331

Package Contents

  • 16- or 24-port Gigabit Ethernet Switch (JGS516 or JGS524)
  • Power cord
  • Installation guide
  • Rack-mount kit
  • Warranty/support information card

NETGEAR Related Products

  • Copper Gigabit PCI Adapter (GA311)
  • 5-port Gigabit Ethernet Switch (GS105)
  • 8-port Gigabit Ethernet Switch (GS108)
  • 16-port Gigabit Ethernet Switch (GS116)

Ordering Information

JGS516

  • North America: JGS516NA
  • Europe: JGS516-100EUS
  • Asia: JGS516AU
  • Japan: JGS516-200JPS

JGS524

  • North America: JGS524NA
  • Europe: JGS524-100EUS
  • Asia: JGS524AU
  • Japan: JGS524-200JPS
