Pure Base 500 FX, Tempered Glass, No PSU, ATX, Black, Mid Tower Case
Quantity:
- SKU: 15083495
- Manufacturer: be quiet!
- MPN: BGW43
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$149.90
Pure Base 500 FX, Tempered Glass, No PSU, ATX, Black, Mid Tower Case
The be quiet! Pure Base 500 FX Black offers impressive lighting with multiple modes and maximum airflow for high cooling performance.
- ARGB lighting at the fans, the front and inside the case
- Multiple colors and modes for an individual look
- 4 Light Wings PWM fans for high airflow and quiet operation
- ARGB-PWM-Hub enables synchronization of up to 6 ARGB components and 6 PWM fans
- High airflow intake front panel and top cover for maximum performance
- USB 3.2 Gen. 2 Type C for latest hardware
- Ready for radiators of up to 360mm
- 3-year manufacturer’s warranty
| General data | |
| Model | Pure Base 500 FX |
| PSU form factor | ATX PS/2 |
| Motherboard compatibility | ATX / M-ATX / Mini-ITX |
| Installation of motherboards with backplate | ✓ |
| Case size excl. stands (L x W x H), (mm) | 450 x 232 x 443 |
| Case size incl. stands (L x W x H), (mm) | 450 x 232 x 463 |
| Dimensions side panel window (L x W), (mm) | 400 x 431 |
| Weight (kg) | 8,0 |
| Color option | Black |
| USB 2.0 | - |
| USB 3.2 Gen. 1 | 1 |
| USB 3.2 Gen. 2 Type C | 1 |
| HD Audio I/O | Mic + Audio |
| Expansion slots | 7 |
| Fan mounting locations | 6 |
| Qi charger / Quick Charging Option | - |
| Material | |
| Top cover | ABS |
| Side panel | Steel |
| Side panel window | 4mm Tempered Glass |
| Front panel | ABS |
| Stands | ABS |
| Drive bay capacity | |
| 5.25 bays | - |
| 3.5 slots (max.) | 2 |
| 3.5 slots (scope of delivery) | 2 |
| 2.5 slots (max.) | 4 |
| 2.5 slots (scope of delivery) | 4 |
| Pre-installed fans | |
| Fan @ top | - |
| Fan @ front | 3x Light Wings PWM 120mm |
| Fan @ rear | 1x Light Wings PWM 140mm |
| Dimensions (L x W x H), (mm) | 120 x 120 x 25 / 140 x 140 x 25 |
| Fan speed @ 100% PWM / 12V (rpm) | 1700 / 1500 |
| Noise level @ 100% PWM / 12V (dB(A)) | 20.6 / 23.3 |
| Airflow @ 100% PWM / 12V (CFM / m3/h) | 41.51 / 70.53 / 56 / 95.14 |
| Air Pressure @ 100% PWM / 12V (mm H2O) | 1.66 / 1.49 |
| Voltage range (V DC) | 5 - 13.2 |
| Input power (W) | 4.56 / 3.84 |
| Input current (A) | 0.07 / 0.08 |
| Connector | 4-pin PWM |
| Lifespan (h / 25°C) | 60,000 |
| Fan controller | PWM and ARGB Hub |
| Maximum fan installation | |
| Front (mm) | 3 x 120 / 2 x 140 |
| Top (mm) | 2x 120 / 2 x 140 |
| Bottom (mm) | - |
| Side panel (mm) | - |
| PSU shroud | - |
| Optional radiator installation | |
| Front (mm) | 120 / 140 / 240 / 280 / 360 |
| Top (mm) | 120 / 240 |
| Bottom (mm) | - |
| Rear (mm) | 120 / 140 |
| Cooling | |
| Max.construction height of CPU cooler unit (mm) | 190 |
| Airflow channel | Front / Top / Rear |
| Lighting | |
| RGB LED illumination | Yes |
| LEDs synchronizable with RGB controller/motherboard | Yes |
| Expandable RGB controller | - |
| PSU compatibility | |
| Maximum dimensions excl. bottom fan (mm) | 258 |
| Maximum dimensions incl. bottom fan (mm) | 225 |
| Graphics card | |
| HDD cage (in height of graphics card) installed (mm) | 369 |
| HDD cage (in height of graphics card) removed (mm) | 369 |
| Insulation and damping | |
| Top panel insulation mats | - |
| Front panel insulation mats | - |
| Side panel insulation mats | ✓ |
| Anti-vibration decoupled HDD | ✓ |
| Anti-vibration decoupled fan | - |
| Anti-vibration decoupled PSU | ✓ |
| Anti-vibration decoupled motherboard-tray | - |
| Removeable dust filters | |
| Front | 1 |
| Bottom | 1 |
| Side panel | 0 |
| Accessories | |
| Screw set (Drives/Motherboard) | ✓ |
| Rubber rail (pcs.) | - |
| Standoff (pcs.) | - |
| LCS bracket (pcs). | 0 |
| HDD slot cover (pcs.) | 0 |
| Upper fan bracket (pcs.) | 0 |
| HDD panel rubber grommet (pcs.) | - |
| SSD bracket for PSU shroud | 0 |
| LED strips (pcs.) | - |
| Cable ties (pcs.) | 6 (Velcro) / 4 (Velcro) |
| Service | |
| Warranty (Years) | 3 |
| International hotline / free of charge | ✓ / DE, FR |
| Logistics data, RRP | |
| Article number | BGW43 |
| EAN code | 4260052189054 |
| Certifications | CE / RoHS |
| Dimensions, package (L x W x H), (mm) | 510 x 285 x 494 |
| Gross weight, package (kg) | 9,2 |
| Pieces per packaging unit | 1 |
