General Data |
Model |
Pure Loop 240mm |
Dimensions radiator, incl. fan (H x W x D), (mm) |
277 x 120 x 52 |
Total weight (kg) |
1.05 |
Socket compatibility |
Intel 1200 / 2066 / 1150 / 1151 / 1155 / 2011(-3) square ILM; AMD: AM4 / AM3(+) |
Fan model, number |
2x Pure Wings 2 120mm PWM high-speed |
Noise level (dB(A)) @ 25 % / 50% /100% rpm |
19 / 26.6 / 39.5 |
Pump speed (rpm) |
5500 |
Pump connector |
3-pin |
Tube length (mm) |
400 |
Refill port |
✓ |
Radiator specifications |
Dimensions (H x W x D), (mm) |
277 x 120 x 27 |
Radiator material / finish |
Aluminum / Black spray painted |
Base material / finish |
Copper / Nickel plated |
Fan specifications |
Fan dimensions (mm) |
120 x 120 x 25 |
Speed @ 100% PWM (rpm) |
2000 |
Bearing technology |
Rifle |
Motor technology |
4-pole fan motor |
Rated Voltage (V) |
12 |
Input current (A) |
0.30 |
Input power (W) |
3.6 |
Connector |
4-pin PWM |
Cable length (mm) |
420 |
Lifespan (h / 25°C) |
80,000 |
Accessories |
Thermal grease |
Included |
Mounting set |
Intel & AMD |
User manual languages |
CN, DE, EN, ES, FR, JP, PL, RU, TW |
Y-cable for fans |
✓ |
Y-SATA Power adaptor for pump & light |
✓ |
Bottle of coolant (ml) |
✓ / 100 |
Service |
Warranty (Years) |
3 |
International hotline / free of charge |
✓ / DE, FR |
Logistics data, RRP |
Article number |
BW006 |
EAN code |
4260052187890 |
Dimensions, package (L x W x H), (mm) |
321 x 140 x 240 |
Gross weight, package (kg) |
1.94 |
Pieces per packaging unit |
8 |
Dimensions, shipping box (L x W x H), (mm) |
658 x 296 x 508 |
Gross weight, shipping box (kg) |
17.00 |
